CC3135MOD
SWRS225B – FEBRUARY 2019 – REVISED MARCH 2020
1.2

Applications

• For Internet of Things applications, such as:
– Medical and Healthcare
• Multiparameter Patient Monitor
• Electrocardiogram (ECG)
• Electronic Hospital Bed & Bed Control
• Telehealth Systems
– Building and Home Automation:
• HVAC Systems & Thermostat
1.3

Description

The CC3135MOD is an FCC, IC/ISED, ETSI/CE, MIC, and Wi-Fi CERTIFIED™ module that dramatically
simplifies the implementation of Internet connectivity. This dual-band Wi-Fi
can be added to any low-cost, low-power microcontroller unit (MCU); it integrates all protocols for Wi-Fi
and Internet, which greatly minimize host MCU software requirements.
This ROM-based subsystem includes an 802.11 a/b/g/n dual-band 2.4 GHz and 5 GHz radio, baseband,
and MAC with powerful hardware cryptographic engine. With built-in security protocols, the CC3135MOD
solution provides a robust and simple security experience. The CC3135MOD is available in an LGA
package that is easy to lay out with all required components including serial Flash, RF filters, diplexer,
crystal, and passive components that are fully integrated.
This generation introduces new capabilities that further simplify the connectivity of things to the Internet.
The main new features of CC3135MOD include:
• 802.11 a/b/g/n: 2.4 GHz and 5 GHz support
• 2.4 GHz Coexistence with Bluetooth
• Antenna diversity
• Enhanced security with FIPS 140-2 level 1 validated IC inside:
• More concurrent secure sockets, up to 16
• Unique device identifier with ability to generate certificate signing request (CSR)
• Online certificate status protocol (OCSP)
®
• Wi-Fi Alliance
• Hostless mode for offloading template packet transmissions
• Improved fast scan
The CC3135MOD device is part of the SimpleLink™ MCU platform—a common, easy-to-use development
environment based on a single-core software development kit (SDK) with a rich tool set and reference
designs. The E2E™ community supports Wi-Fi
more information, visit www.ti.com/SimpleLink.
PART NUMBER
CC3135MODRNMMOBR
(1) For more information, see
2 Module Overview
®
low energy radio
certified for IoT low power capabilities
Table 1-1. Module Information
Section 10.
Submit Documentation Feedback
Product Folder Links:
• Video Surveillance, Video Doorbells, and
Low-Power Camera
• Building Security Systems and E-locks
– Appliances
– Asset Tracking
– Factory Automation
– Grid Infrastructure
certification
® ®
, Bluetooth low energy, Sub-1 GHz, and host MCUs. For
(1)
PACKAGE
QFM (63)
Copyright © 2019–2020, Texas Instruments Incorporated
CC3135MOD
www.ti.com
®
network processor module
BODY SIZE
20.5 mm × 17.5 mm
®
