While no CW transmit IF signal exists, 039 and 023 turn
the switching diode (D35) OFF to ensure transmit isolation.
4-2·9 OUTPUT POWER METER CIRCUITS
(MAIN UNIT)
The "FOR" voltage from the PA UNIT is applied to the Po
meter amplifier (IC10 pin 3) and then to the meter. R189
and C261 are used for peak power measurement.
4-2·10 T/R SWITCHING CIRCUIT
(MAIN UNIT)
When the PTT or [TRANSMln switch is set to transmit,
IC13 pin 10 and IC13 pin 3 are "LOW." At this time,
049 turns ON, and O Vis present on the ''R8" voltage line.
050 turns OFF, and there is 8 V present on the "T8"
voltage line.
When the PTT or [TRANSMln switch is set to receive,
IC13 pin 10 and IC13 pin 3 are "HIGH." At this time,
049 turns OFF, and 8 V is present on the "RB" voltage
line. 050 turns ON, and there-is O V present on the
"T8" voltage line.
When PLL data or the operating mode is changed, the
"DNB" signal line becomes "LOW," turning OFF the
TB -
preventing unwanted transmission.
4.3 PLL CIRCUITS
4·3·1 GENERAL DESCRIPTION
The PLL UNIT generates a 1st LO signal (70.9515-
100.4515 MHz variable) and 2nd LO signal (61.44 MHz
fixed) used in the MAIN UNIT. The IC-725 uses a dual loop
PLL system. A main loop PLL uses 4 VCO circuits for
all HF band coverage within 512 kHz steps. A sub loop
PLL uses a DDS (Direct Digital Synthesizer) system for
512 kHz coverage within 10 Hz steps. The DDS system
provides a rapid lockup time and high quality frequency
oscillation.
4-3·2 REFERENCE OSCILLATOR CIRCUIT
(PLL UNIT)
A 30.72 MHz reference frequency is produced by the
oscillator 033 and X2. The reference frequency, buffer-
amplified at 034, is divided by 2 at IC15 and is then
applied to the PLL circuit as the PLL reference frequency.
The signal oscillated at 033 is multiplied by 2 at 036. The
resulting 61.44 MHz signal is filtered at the bandpass
filter and is then applied to the MAIN UNIT via P4 as
the 2nd LO signal.
4.3.3 MAIN LOOP (PLL UNIT)
The main loop uses a PLL IC (IC13) which contains a
programmable divider, phase detector, data shift register
and data latch circuits. The main loop generates
70.9515-100.4515 MHz signals in 512 kHz steps.
4-6
Because the sub loop produces 1 O Hz steps, the PLL
produces a 30 MHz frequency range in 10 Hz steps.
The oscillated signal at one of the 4 VCOs (015, 017,
019, 021 ; see Section 4-3-4 for details) is amplified at 023.
The signal is mixed with the sub loop output (fLO:
62.05-62.56199 MHz) at IC16. 023 is an isolator which
ensures that the mixer input does not affect the VCO
output.
The mixed signal is amplified at 027 and is then filtered
at the low-pass filter (L23-L25, C92, C93, C99-C103).
The filtered signal, amplified at 026, is divided by 4 at
IC14 and is then applied to the PLL IC (IC13).
The phase of the divided signal at IC14, detected at
the PLL IC (IC13) using a reference frequency (fREF) of
512 kHz, is then output from pin 17. The 512 kHz
frequency is obtained from the reference oscillator (033).
30.72 MHz oscillated at 033, is divided by 2 at IC15 and
divided by 30 at the programmable divider section of IC13.
The phase detected signal is then converted to the lock
voltage at the loop filter (012-014), and applied to the
VCO. Thus, the VCO output (PLL output) is locked to
produce stable oscillation.
The PLL oscillation frequency is obtained by the following
calculation:
fv=fLo+NrxfREF
fv : Main loop output
fLO : Sub loop output
Nr : Dividing· ratio from the CPU
fREF: Reference frequency (512 kHz)
4.3.4 VCO CIRCUIT (PLL UNIT)
The transceiver's C/N ratio is determined by the VCO and
the loop filter. 4 VCO circuits keep the low noise and
reduce spurious emissions. 016, 018, 020 and 022 are
VCO switches which select the operating VCO with
"VC01"-"VC04" lines.
4.3.5 SUB LOOP (PLL UNIT)
The sub loop uses the DDS system that generates
62.05-62.56199 MHz signals in 10 Hz steps.
The oscillated signal at the VCO (029) is buffer-amplified at
030 and mixed with the 2nd LO signal (61.44 MHz) at
IC17. The resulting signal passes through the low-pass
filter, is amplified at 032, and is then applied to the DDS
UNIT.
The output pulse-type signal from the DDS UNIT passes
through the loop filter (R133, R134, C114, C115, L42)
where it is converted into a DC signal (lock voltage). The
lock voltage is applied to the VCO to lock the oscillating
frequency.
