- Page 1 UCC MMI-2 installation guide www.renishaw.com UCC MMI-2 installation guide Documentation part number: H-1000-7605-02-B Issued 08 2020...
-
Page 2: General Information
Renishaw warrants its equipment and software for a limited period (as set out in the Standard Terms and Conditions), provided that they are installed and used exactly as defined in associated Renishaw documentation. You should consult these Standard Terms and Conditions to find out the full details of your warranty. -
Page 3: Care Of Equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with care. Changes to Renishaw products Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to Renishaw equipment previously sold. Company registration details Renishaw plc. -
Page 4: Product Compliance
Information to user (47 CFR 15.21) The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or authorised representative could void the user's authority to operate the equipment. - Page 5 UCC MMI-2 installation guide www.renishaw.com Issued 08 2020...
-
Page 6: Installation Requirements
The UCC MMI-2 controller is only warranted and approved for use with the provided PSU. The UCC MMI-2 is isolated from ac power by disconnection of the IEC mains connector from the supplied PSU. If any additional means of isolation is required, it must be specified and fitted by the machine manufacturer or installer of the product. The isolator / disconnection device must be sited within easy reach of the operator and comply with IEC61010 and any applicable national wiring regulations for the country of installation. -
Page 7: Environmental Conditions
50% at +50 °C Pollution degree NOTE: If the UCC MMI-2 is to be used in an environment where a higher IP rating is required, then the UCC MMI-2 will need to be housed in a suitable enclosure. -
Page 8: References And Associated Documents
UCC MMI-2 installation guide www.renishaw.com References and associated documents It is recommended that the following documentation is referenced when installing the UCC MMI-2: Renishaw documents Title Document number Guide: Product interconnection system (PICS) H-1000-5000 UCCassist-2 help Found within UCCassist-2 External documents... - Page 9 Introduction The UCC MMI-2 controller provides a USB based interface for manual CMMs. The UCC MMI-2 interfaces to the Renishaw digital range of scale readheads, or electrically compatible OEM versions, and to TP20 or similar touch-trigger probes. The UCC MMI-2 controls the collection of scales data, and latches the scales positions when a touch-trigger event is detected.
- Page 10 Supports manual CMM data collection Three CMM axes can be interfaced by the UCC MMI-2 Supports incremental encoders The UCC MMI-2 can automatically adjust the supply voltage to encoder readheads (to compensate for cable losses) Probe interface (PICS) Supports manual heads...
-
Page 11: General Wiring Standards
All signal cables MUST be screened and all cable screens should be connected electrically to the cable connector's metal shells. It is recommended that cable screens should only be connected to the functional earth (via the connector shell) of the UCC MMI-2. To avoid earth loops, cable screens should not be directly attached to the CMM's functional earth. -
Page 12: Freestanding Installation
44 mm (1.7 in) 2.1 kg (4 lb 10 oz) The UCC MMI-2 can either be free-standing or used in a 19 inch rack system. WARNING: Ensure the UCC MMI-2 is disconnected from the mains supply during installation. Free-standing installation Four self-adhesive feet are supplied with the unit for non-rack mounted installations. - Page 13 NOTE: The screws supplied with this kit are M5 × 6 mm countersink type. The rack mounting kit (Renishaw part number A‐5518‐0005﴿ contains two brackets and four M5 × 6 mm screws. Assemble the brackets to the UCC MMI-2 as shown below:...
-
Page 14: Earth Bonding Scheme
UCC MMI-2 installation guide www.renishaw.com Earth bonding scheme * NOTE: May be protective earth where appropriate for electrical safety. Issued 08 2020... -
Page 15: Software Installation
Software installation Support for the UCC MMI-2 is included in UCCsuite version 5.5 and onwards. All recommended updates for any of the system components must be installed for correct operation. The UCCassist-2 application included in this software release will allow the user to correctly configure the system to use the UCC MMI-2. -
Page 16: Connectors And Signals
UCC MMI-2 installation guide www.renishaw.com Connectors and signals This section contains information on the following UCC MMI-2 ports: Scale interface (15W HDD socket) Machine I/O (44W HDD socket) PICS (9W D socket) USB connection (USB type B) UCC MMI-2 power socket (6.3 mm socket) -
Page 17: Connector Details
UCC MMI-2 installation guide www.renishaw.com Scale interface ﴾3 × 15W HDD sockets﴿ UCC MMI-2 provides a digital interface for Renishaw digital incremental encoders. UCC MMI-2 can also be used with compatible 3rd party encoders. Connector details The ports use 15-way high-density 'D' sockets. The connections for the sockets are shown in the table below. - Page 18 The scale inputs support a quadrature waveform with a minimum edge separation of 50 ns, which equates to 20 million counts per second with an ideal waveform. Encoder resolution Maximum move speed 1 µm 20 m/s 0.1 µm 2 m/s 50 nm 1 m/s 1 nm 0.02 m/s UCC MMI-2 scale signal interface circuit Issued 08 2020...
- Page 19 UCC MMI-2 scale error interface circuit The UCC MMI-2 supports the error signal provided by Renishaw's digital incremental encoders. The UCC MMI-2 can also detect tri-state conditions on the A and B signals. If the error signal is not integrated into the connected encoder, then the user should connect pin 3 (Error - ) to pin 7 ( +V scale).
- Page 20 The machine I/O socket is used to provide connections for the CMM input / output. The cable needs to be created by the CMM installer using the pin out guide below. The connector for the machine I/O socket is provided within the UCC MMI-2 kit.
- Page 21 The inputs are activated by being pulled down to 0 V. They are not opto isolated and are pulled up to +24 V by a 10 kΩ resistor within the UCC MMI-2. These inputs can accept signal levels in the range of +5 V to +24 V, and need to be pulled below 1.5 V to signify the active state.
- Page 22 UCC MMI-2 installation guide www.renishaw.com Enable air solenoid An active low signal to engage an air solenoid. Uncommitted inputs These input pins can be configured to the customer's requirements via the UCCsuite software. Uncommitted outputs These output pins can be configured to the customer's requirements via the UCCsuite software.
- Page 23 PICS LED anode Probe signal Reserved /PICS PDAMP/ (active low) probe damping /PICS LEDOFF/ (active low) LED off Shell Screen Please refer to the PICS installation guide (Renishaw part number H-1000-5000) for further information when interfaces are fitted. Issued 08 2020...
- Page 24 Communication to a PC will be via a standard USB-A to USB-B cable using the USB 2.0 protocol supporting up to full-speed mode. A 5 m USB cable is provided for this link as part of the UCC MMI-2 kit. Other lengths may be used; the maximum being 5 m which is governed by the generic specification for USB connections.
- Page 25 MMI-2 controller is only warranted and approved for use with the provided PSU. The PSU provides the UCC MMI-2 with up to 72 W at +24 Vdc. The UCC MMI-2 power socket interfaces with a dc jack plug, 2.5 mm inner diameter, 5.5 mm outer diameter, centre positive.
-
Page 26: Testing And Verification
Testing and verification The machine manufacturer or the installer of the UCC MMI-2 is responsible for ensuring that the following testing and verification is performed to the appropriate standard: Verification that the electrical equipment is in compliance with the technical documentation... -
Page 27: Maintenance
UCC MMI-2 installation guide www.renishaw.com Maintenance NOTE: There are no user serviceable parts inside this unit. Periodically check that all mounting screws and electrical connectors are securely tightened. Electrical safety checks should include inspecting the mains cable for damage and the safety of the connections. -
Page 28: Troubleshooting
UCC MMI-2 installation guide www.renishaw.com Troubleshooting UCC MMI-2 visual diagnostics A visual indication of the system status is provided by two LEDs on the front panel, providing assistance in diagnosing and rectifying system faults. LED status key Description LED on, displaying green, amber or red... -
Page 29: Fatal Faults
Situations can occur that make it inadvisable or dangerous to continue using the CMM system. These are known in UCCsuite as fatal faults. A list of UCC MMI-2 related fatal faults is shown below and will be indicated through the user's software (for example MODUS):... - Page 30 Renishaw plc +44 (0)1453 524524 New Mills, Wotton-under-Edge +44 (0)1453 524901 Gloucestershire, GL12 8JR United Kingdom www.renishaw.com/cmmsupport For worldwide contact details, please visit our main website at www.renishaw.com/contact Issued 08 2020...
