UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com UCC T3 PLUS and UCC S3 CMM controller installation guide Documentation part number: H-1000-2118-02-B Issued 01 2018...
Page 2
Renishaw distributor. Warranty Renishaw plc warrants its equipment for a limited period (as set out in our Standard Terms and Conditions of Sale) provided that it is installed exactly as defined in associated Renishaw documentation. Prior consent must be obtained from Renishaw if non-Renishaw equipment (e.g. interfaces and/or cabling) is to be used or substituted.
Page 3
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with care. Changes to Renishaw products Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to Renishaw equipment previously sold. Packaging...
Page 4
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com EU declaration of conformity Contact Renishaw plc or visit www.renishaw.com/productcompliance for the full EU declaration. Issued 01 2018...
Page 5
Information to user (47CFR section 15.21) The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or an authorised representative could void the user's authority to operate the equipment.
Page 6
Installation category II The UCC T3 PLUS or UCC S3 is isolated from the ac power by disconnection of the IEC mains connector from the supplied PSU. If any additional means of isolation is required, it must be specified and fitted by the machine manufacturer or installer of the product. The isolator / disconnection device must be sited within easy reach of the operator and comply with any applicable national wiring regulations for the country of installation.
Page 7
Transient voltages Installation category II Pollution degree * NOTE: It may be necessary to house UCC T3 PLUS / UCC S3 in a suitable enclosure according to the installation's environmental conditions to obtain a higher IP rating. Issued 01 2018...
Page 8
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com References and associated documents It is recommended that the following documentation is referenced when installing the UCC T3 PLUS or UCC S3: Renishaw documents Title Document number Installation and user's guide: PH10 PLUS...
Page 9
PC - connects to UCC T3 PLUS / UCC S3 via an Ethernet cable MCR20 rack The UCC T3 PLUS / UCC S3 is a controller in a 19 inch rack-mountable enclosure. It is coupled to the CMM host computer by an Ethernet link and to the CMM via external cable interface connectors.
Page 10
UCC T3 PLUS or UCC S3. WARNING: UCC T3 PLUS / UCC S3 are not compatible with PH9, PHS, PH20 and REVO systems. No attempt should be made to connect these system components to the UCC T3 PLUS or UCC S3 as this will result in damage to the product or attached equipment.
Page 11
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com UCC S3 Rear panel layout Description Connector polarity Multiwire connection SOCKET PICS SOCKET Temperature compensation connector PLUG Ethernet communications connector to CMM computer SOCKET Reset button / IP configure button...
Page 12
If the host PC is connected to a network, it is necessary to install additional hardware to allow a dedicated connection for UCC T3 PLUS or UCC S3 communication. For details on how to install additional hardware on the host PC, please refer to the manufacturer user's guide.
Page 13
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com IP configure / reset button Number 5 on the rear panel is the reset button which has two different functions. The function depends on the operational state of the controller.
Page 14
Weight: 2.1 kg (4 lb 10 oz) UCC T3 PLUS or UCC S3 (CMM controller) can either be free standing or used in a 19 inch rack system. CAUTION: Ensure the controller is disconnected from the power supply during installation.
Page 15
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Issued 01 2018...
Page 16
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com PH10 head connector (15-way 'D' type socket) NOTE: For maximum immunity from electrical noise, Renishaw recommends that: 1. Mating shells connectors must be metal bodied. 2. The overall cable screen is continuous and connected to the system ground on the user's equipment through the bodies of the connectors.
Page 17
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Machine cable: Probe head cable: Issued 01 2018...
Page 18
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Controller Controller Head Head Maximum Signal name 15-way male 'D' type Cable PLM 6 - 9 14-way LEMO 12-core 14-way Current B-axis feedback Black (F) 1 (M) Yellow Ground sense / head present...
Page 19
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Temperature compensation connector (37 way D-type plug) Pin number Description Pin number Description Channel 1 input Channel 1 return Channel 2 input Channel 2 return Channel 3 input Channel 3 return...
Page 20
Renishaw's PICS allows a standard method of connection for real-time signals used by current Renishaw products. Please refer to the PICS installation guide (Renishaw part number H-1000-5000) for further information when interfaces are fitted. NOTE: TP7 is not supported with this product.
Page 21
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com System interconnection diagrams PH10 PLUS system with standard two wired touch-trigger probes Description Description Head cable(s) MCU connection RJ45 cable (supplied) SCR200 rack connection 16 / 0.2 mm earth connection...
Page 22
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com PH10 PLUS system with multiwire scanning probes Description Description Head cable(s) MCU connection RJ45 cable (supplied) Multiwire cable 16 / 0.2 mm earth connection Issued 01 2018...
Page 23
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Temperature compensation NOTE: Thermal compensation is activated and setup through UCCassist-2. For installation and setup details refer to the TEC installation guide (Renishaw part number H-1000-5105). Issued 01 2018...
Page 24
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Troubleshooting Front panel LEDs UCC T3 PLUS or UCC S3 visual diagnostics LED status key: Description LED on LED flashing off / on LED flashing green / red LED off...
Page 25
Fast flash (5 Hz) - no controller ID in IP configuration mode - return to Renishaw NOTE: A scale error will cause the UCC T3 PLUS or UCC S3 to enter an error state which is not recoverable within a metrology application environment.
Page 26
Use the tables below to identify problems you are experiencing with your PH10 PLUS system. If you experience problems which you are not able to identify or solve satisfactorily, please contact Renishaw for further advice. No head movement in automatic mode:...
Page 27
Filter replacement UCC T3 PLUS or UCC S3 uses an internal air flow for cooling purposes. This system has a replaceable filter to minimise the ingress of dust. The condition of the of the filter should be checked on a regular basis. It is recommended that this filter is removed and checked / replaced as necessary or every 12 months.
Page 28
UCC T3 PLUS and UCC S3 CMM controller installation guide www.renishaw.com Advisory It is recommended that periodical metrology tests are performed in order to identify any faults in subsystems eg air bearings, structure, cables, software etc. Issued 01 2018...
Page 29
Renishaw plc +44 (0)1453 524524 New Mills, Wotton-under-Edge, +44 (0)1453 524901 Gloucestershire, GL12 8JR United Kingdom www.renishaw.com/cmmsupport For worldwide contact details, please visit our main website at www.renishaw.com/contact Issued 01 2018...
