- Page 1 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com UCC S5 REVO-2 CMM controller installation guide Documentation part number: H-1000-7598-03-D Issued 08 2019...
-
Page 2: General Information
Renishaw distributor. Warranty Renishaw plc warrants its equipment for a limited period (as set out in our Standard Terms and Conditions of Sale) provided that it is installed exactly as defined in associated Renishaw documentation. Prior consent must be obtained from Renishaw if non-Renishaw equipment (e.g. interfaces and/or cabling) is to be used or substituted. Failure to comply with this will invalidate the Renishaw warranty. -
Page 3: Care Of Equipment
Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with care. Changes to Renishaw products Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to Renishaw equipment previously sold. Packaging... -
Page 4: Product Compliance
Information to user (47 CFR 15.21) The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or authorised representative could void the user's authority to operate the equipment. -
Page 5: China Rohs
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com China RoHS Contact Renishaw plc or visit www.renishaw.com/ChinaRoHS for the full China RoHS tabulation. Issued 08 2019... - Page 6 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Safety If the equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be impaired. There are no user serviceable parts inside the equipment.
-
Page 7: Enviromental Conditions
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Enviromental conditions Indoor use IP30* (BS EN60529:1992) Altitude Up to 2000 m Operating temperature +5 °C to +50 °C Storage temperature ‐25 °C to +70 °C Relative humidity 80% maximum ﴾non‐condensing﴿ for temperatures up to +31 °C Linear decrease to 50% at +50 °C... -
Page 8: References And Associated Documents
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com References and associated documents It is recommended that the following documentation is referenced when installing the UCC S5: Renishaw documents Title Document number Installation guide: REVO-2 H-1000-7590 Installation guide: SPA3 H-1000-7566 Installation and user's guide: MCU... - Page 9 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Introduction The UCC S5 is the latest generation Renishaw CMM controller product and supports the second generation REVO-2 measurement head. Issued 08 2019...
- Page 10 REVO-2 directly support one or two Renishaw SPA3 servo power amplifiers (two SPA3 units will be required for machines with additional axes i.e. dual drive, rotary table)
- Page 11 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Front panel UCC S5 Rear panel layout Description Description 37-way D-type plug for Reserved temperature compensation Ethernet communications Reserved connector to CMM computer Reset button 15-way D-type socket for REVO- 2 connection...
-
Page 12: Stand-Alone Installation
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Installation Dimensions Width Depth Height Weight 440 mm (17.3 in) 180 mm (7.1 in) 44 mm (1.7 in) 2.1 kg (4 lb 10 oz) UCC S5 can either be free standing or used in a 19 inch rack system. -
Page 13: Mounting In A 19 Inch Rack
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Mounting in a 19 inch rack The rack mounting kit ﴾part number A‐5518‐0005﴿ contains two brackets and four M5 × 6 mm screws. Assemble the brackets to the UCC S5 as shown below:... -
Page 14: General Wiring Standards
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com General wiring standards To achieve reliable operation of the UCC S5 and the CMM's host computer, the following points should be observed: All signal cables MUST be screened and all cable screens must be connected electrically to the metal shells of the cable connectors... -
Page 15: Reset Button
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Reset button The rear panel reset button has two different functions. The function depends on the operational state of the controller. 1. Pressing and releasing the reset button within 15 seconds of switching on the unit will force the controller into IP configuration state. -
Page 16: System Connection
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com System connection Earth bonding scheme Issued 08 2019... - Page 17 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Installation for up to 3 axes with head cable less than 25 m Description Description Orange head cable 24 V power supply (supplied) Cat 5 300 mm cable (supplied) 25 V - 80 V power supply (not supplied) 16 / 0.2 mm earth connection...
- Page 18 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Installation for 4 - 6 axes with head cable exceeding 25 m and thermal effect compensation (TEC) Description Description Orange head cable 25 V - 80 V power supply (not supplied) Cat 5 300 mm cable (supplied) Air filter 16 / 0.2 mm earth connection...
- Page 19 Head comms signal booster box installation When using the Renishaw high-speed communications cable (orange cable) with Renishaw's 5-axis products, the maximum permissible cable length is 25 m. Where runs of greater than 25 m are needed between the machine controller and probe head, a head comms signal booster (HCSB) must be inserted.
-
Page 20: Cable Connections
It is mandatory that the Renishaw universal machine cable is used. Various lengths of cable are available and include pre-crimped options for ease of installation. The following image shows the pin numbers for each connector end view of the Renishaw universal machine cable. 15-way HDD socket pin... - Page 21 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Preparation of Renishaw universal machine cable for quill mounted systems Preparation of Renishaw universal machine cable for shank mounted systems Issued 08 2019...
-
Page 22: Temperature Compensation Connector
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Temperature compensation connector Pin number Channel Pin number Channel Channel 1 input Channel 1 return Channel 2 input Channel 2 return Channel 3 input Channel 3 return Channel 4 input Channel 4 return... -
Page 23: Connecting The Ucc Controller
The UCCassist-2 software must be installed on the host PC prior to connection of the UCC controller. The latest version of UCCsuite can be downloaded from the Renishaw website for anyone with a MyRenishaw account. UCCsuite will install UCCassist-2 and UCCserver to enable the hardware set-up. - Page 24 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com IP addressing Choose an IP address for the UCC controller and an IP address for the PC's network adaptor that are of the same class: class A 1.0.0.1 – 126.255.255.254 For class A networks, a network is defined by the first number.
- Page 25 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Setting the IP address of the PC The process to set the IP address on the PC varies with each version of Windows. Administrator rights are needed in order to perform this operation.
- Page 26 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com c﴿ Click on 'Properties' and select ‘Internet Protocol ﴾TCP/IPv4﴿' and click 'Properties'. d﴿ Select ‘Use the following IP address' and type in the IP address to use for the PC end of the comms link. Click in the Subnet mask field. On Windows10 the Subnet mask will already be filled in.
- Page 27 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com e) Click 'OK' and then 'OK' again. On earlier versions of Windows the PC needs to be rebooted. Setting the IP address of the UCC controller The UCC controller is not intended to be used on a corporate network. It is extremely important that the setting of the IP address of the UCC controller is on a dedicated connection.
- Page 28 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com b) Pressing 'Next' will bring up a screen to allow the specific controller to be selected. It will also give instructions on getting the controller into IP configure mode depending on if it has already been configured or has no current configuration.
- Page 29 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com d) The UCC controller does not have an IP address. Type in the relevant address to match the network adapter in the PC. In the case below this is 10.0.0.1: e) Fill in the desired IP address. The IP configuration software has given you a head start by filling in the network part of the address appropriate for the network adapter selected (see section 'IP addressing' for a discussion of the choice and of IP addresses in general).
- Page 30 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com f﴿ Click on ‘Configure PC and UCC pair'. If all is well this will result in the address being applied to the controller and the IP configure screen will close. If the controller is already configured a dialogue box saying the UCC is configured will open. Click 'Next' to finish.
- Page 31 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Changing the IP address of the UCC If the UCC controller already has an IP address, after booting up it skips its IP configuration state and proceeds into waiting for a download, shown by the status LED flashing slowly.
-
Page 32: Temperature Compensation
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Temperature compensation NOTE: Thermal compensation is activated and setup through UCCassist-2. Axis sensors Axis sensors are required to monitor and compensate for any temperature changes within the CMM's scale. The axis sensor is housed in a potted ring terminal with a Ø3.7 mm hole which can be screwed or glued in position using a thermally conductive glue. -
Page 33: Sensor Resistance Checks
Ensure the CMM is not subjected to unnecessary changes in temperature (fans blowing, close to radiator, in direct sunlight or any other powerful radiant sources) Excessive humidity should be avoided Use the system as close as possible to the calibrated temperature Renishaw recommends that workpiece and axis sensors are verified at six month intervals Issued 08 2019... -
Page 34: System Accuracy And Calibration
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Workpiece sensor Ensure the workpiece sensor is in full contact with the workpiece Aim to position the workpiece sensor in the middle of the workpiece or near where the measurement is taking place... -
Page 35: Testing And Verification
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Testing and verification The machine manufacturer or the installer of the UCC S5 is responsible for ensuring that the following testing and verification is performed to the appropriate standard: Verification that the electrical equipment is in compliance with the technical documentation... -
Page 36: Troubleshooting
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Troubleshooting UCC S5 visual diagnostics A visual indication of the system status provided by a multicoloured LED on the front panel. The LED provides assistance in diagnosing system faults. LED status key:... -
Page 37: Fatal Faults
Slow flash - problem with download - reboot required (check file type) Continuous LED - UCC S5 overheated Slow flash - unit does not have controller ID - return to Renishaw Fast flash (5 Hz) - no controller ID in IP configuration mode - return to Renishaw Fatal faults Situations can occur that make it inadvisable or dangerous to continue using the CMM servo system. -
Page 38: Motors Will Not Engage / Re-Engage
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Motors will not engage / re-engage Symptoms Either the servo drives will not engage when the controller has been sent the ‘engage' command, or the drives have disengaged automatically and will not re-engage. -
Page 39: Maintenance
UCC S5 REVO-2 CMM controller installation guide www.renishaw.com Maintenance WARNING: Maintenance should only be carried out after the machine has been isolated from the electrical supply, compressed air supply or other energy sources in accordance with the machine manufacturer's instructions. - Page 40 UCC S5 REVO-2 CMM controller installation guide www.renishaw.com NOTE: There are no user serviceable parts inside this unit. Issued 08 2019...
