Summary of Contents for Renishaw UCC MMI
- Page 1 UCC MMI installation guide http://www.renishaw.com UCC MMI installation guide Documentation part number: H-1000-5362-01-A Issued 11 2017...
-
Page 2: General Information
Renishaw distributor. Warranty Renishaw plc warrants its equipment for a limited period (as set out in our Standard Terms and Conditions of Sale) provided that it is installed exactly as defined in associated Renishaw documentation. Prior consent must be obtained from Renishaw if non-Renishaw equipment (e.g. interfaces and/or cabling) is to be used or substituted. - Page 3 Renishaw probes and associated systems are precision tools used for obtaining precise measurements and must therefore be treated with care. Changes to Renishaw products Renishaw reserves the right to improve, change or modify its hardware or software without incurring any obligations to make changes to Renishaw equipment previously sold. Packaging...
-
Page 4: Eu Declaration Of Conformity
UCC MMI installation guide http://www.renishaw.com EU declaration of conformity Contact Renishaw plc or visit www.renishaw.com/productcompliance for the full EU declaration. Issued 11 2017... -
Page 5: Information To User (47Cfr Section 15.105)
Information to user (47CFR section 15.21) The user is cautioned that any changes or modifications not expressly approved by Renishaw plc or an authorised representative could void the user's authority to operate the equipment. - Page 6 Installation category II The UCC MMI is isolated from ac power by disconnection of the IEC mains connector from the supplied PSU. If any additional means of isolation is required, it must be specified and fitted by the machine manufacturer or installer of the product. The isolator / disconnection device must be sited within easy reach of the operator and comply with any applicable national wiring regulations for the country of installation.
-
Page 7: Environmental Conditions
Relative humidity for storage 80% maximum (noncondensing) for temperatures up to +31 °C Linear decrease to 50% at +50 °C Transient voltages Installation category II Pollution degree * NOTE: It may be necessary to house UCC MMI in a suitable enclosure according to the installation's environmental conditions to obtain a higher IP rating. Issued 11 2017... -
Page 8: General Wiring Standards
All signal cables MUST be screened and all cable screens should be connected electrically to the cable connector's metal shells. Cable screens should only be connected to the protective earth (via the connector shell) at the UCC MMI end, and not directly connected to the CMM protective earth. - Page 9 Renishaw 2-wire kinematic touch-trigger probes are supported. The UCC MMI is housed in a 1U 19 inch rack-mountable enclosure. It is coupled to the CMM host computer by a USB 1.1 link and to the CMM by external cable interface connectors. A rack mounting kit is available as an optional extra.
-
Page 10: Ucc Mmi Features
I/O connections to limit switches, air pressure and other digital inputs and outputs TTP interface The UCC MMI unit incorporates the circuitry and software necessary to interface with the Renishaw TP20, TP1, TP2 and TP6 probes. Power supply unit The UCC MMI requires an external 24 Vdc 2.5 A power supply. -
Page 11: Front Panel Led Displays
During system file downloading, the 'power on' LED is on and the 'error' LED is slowly flashing. If the system file download fails then the 'power on', 'error' and 'system ready' (flashing) LEDs will be on. In this condition, the UCC MMI waits for a system restart. - Page 12 UCC MMI installation guide http://www.renishaw.com Probe seated LED When the probe is not deflected the 'probe seated' LED is on. When the probe is deflected the 'probe seated' LED is off. Issued 11 2017...
-
Page 13: Connectors And Signals
UCC MMI installation guide http://www.renishaw.com Connectors and signals The connectors on the rear panel of the UCC MMI controller enclosure are shown below: Description Connection Equipotential bonding point X-axis scale 15-way high-density D Y-axis scale 15-way high-density D Z-axis scale... -
Page 14: Connecting The Ucc Mmi To A Cmm
UCC MMI installation guide http://www.renishaw.com Connecting the UCC MMI to a CMM Switched inputs Air pressure The controller monitors the input and will signal to the software if it goes open circuit or high. If not required the input should be connected to the 24 V return line. -
Page 15: Generic Ucc I/O Connector
UCC MMI installation guide http://www.renishaw.com Generic UCC I/O connector Issued 11 2017... -
Page 16: Cmm Readhead Input Connections
The X, Y and Zaxis measuring scale readhead input connectors are highdensity 15way ‘D' sockets. The X, Y and Z-axis scale readheads of the CMM must be connected to the relevant socket on the rear panel of the UCC MMI enclosure. Suggestion: Label all readhead connectors to avoid cross connection if removed and replaced in the future. - Page 17 Screen * The UCC MMI is capable of supporting both single and dual limit-switch RG22 readheads. The electronic circuits can interface either type without any intervention but the correct type must be set in the machine ini file. If dual limit types are fitted pin 11 functions as the second limit switch.
-
Page 18: Ucc Mmi To Cmm Measuring Scale Readhead
CMM readhead interface circuit The signals from a readhead or interpolator should be to EIA specification RS-422. UCC MMI input circuits for CMM readhead - scale and reference mark inputs: NOTE: If error inputs are not used or the readhead type is RGH24, connect the –Error input to +5 V. UCC MMI input circuit for CMM readhead - limit switch inputs: UCC MMI input circuit for CMM readhead – error input:... -
Page 19: Switched Outputs
Switched outputs The UCC MMI has the following uncommitted switched output. Pin 6 is the uncommitted output available on the UCC MMI I/O connector. The UCC MMI does not directly control the operation of this output, as it is controlled from the application software package via ‘command 318, Write to controller port'. The output is pulled up to the 24 V rail by a 20 kΩ resistor when inactive, and will be pulled down to the 24 V return line via an NPN transistor when activated. There is an excess voltage protective diode fitted internally to the controller. This output is suitable for driving inputs in the range 5 V to 24 V. -
Page 20: Usb Connection
The UCC MMI uses the USB1.1 specification communication link. A 5 m USB cable is provided for this link as part of the UCC MMI kit. Other lengths may be used; the maximum being 5 m which is governed by the generic specification for USB connections. -
Page 21: Pics Connector
UCC MMI installation guide http://www.renishaw.com PICS connector This socket is intended for use with the TP1,TP2,TP6 or TP20 touch-trigger probes. The connector is a 9-pin D socket, pinout as follows: Pin number Function PICS STOP PICS probe power off (PPOFF) -
Page 22: The Controller - 24 V Supply
The supply to the scale readheads is a nominal 5.25 Vdc. It compensates for any cable volt drop. WARNING: There is no internal fuse on the power supply to the UCC MMI. The installer must provide suitable protection. The maximum current demand of the UCC MMI is 2.5 A at 24 V. -
Page 23: Cmm Host Computer
UCC controller operation. A minimum specification of 1 GHz processor speed and 256 MB RAM is recommended. For UCC MMI only, one free USB port is required for the communication. It is recommended NOT to use a USB hub because of the reduction in speed of operation these devices normally produce. -
Page 24: Installation Software
UCC MMI installation guide http://www.renishaw.com Installation software Compatible software The UCC MMI is only compatible with UCCsuite 4.8. Please use the latest release of UCCsuite 4.8. UCCassist-2 The UCCassist-2 software offers the following capabilities: Basic machine system diagnostics Operation with Renishaw's machine checking gauge, enabling the user to complete frequent volumetric accuracy tests to ensure the... -
Page 25: Testing And Verification
Testing and verification The manufacturer of the finished machine, or the installer of the UCC MMI, is responsible for ensuring that the following testing and verification, to the appropriate standards, is performed as a minimum on the complete installation. -
Page 26: Maintenance
UCC MMI installation guide http://www.renishaw.com Maintenance WARNING: Maintenance should only be carried out after the machine has been isolated from the electrical supply, compressed air supply, or other energy sources in accordance with the machine manufacturer's instructions. Periodically, check the security of mounting screws and electrical connectors. - Page 27 Renishaw plc +44 (0)1453 524524 New Mills, Wotton-under-Edge, +44 (0)1453 524901 Gloucestershire, GL12 8JR United Kingdom www.renishaw.com/cmmsupport For worldwide contact details, please visit our main website at www.renishaw.com/contact Issued 11 2017...
