Optional Accessories; Power Supply Cable - SMC Networks HECR Series Manual

Series

Optional Accessories

q Power Supply Cable
í For single-phase 100/115 V AC type
∗ Not applicable for the 200 V type.
Part no. Applicable model
HECR002
HECR004
HRS-CA001
HECR006
HECR008
∗ Not applicable to the retaining clip.
Part no. Applicable model
HECR002
HECR004
HRS-CA003
HECR006
HECR008
∗ Applicable to the retaining clip.
í For single-phase 200 V AC type
∗ Also applicable for the 100 V AC type, but the connector for the
user's equipment needs to be prepared by the user.
Part no. Applicable model
HECR002
HECR004
HRS-CA002
HECR006
HECR008
HECR010
∗ Applicable to the retaining clip.
í Retaining clip
Holds the connector on the thermo-con side in position.
Part no. Applicable power supply cable model
HRS-S0074
Power supply connector for accessory
HECR
Thermo-con side
Thermo-con side
Thermo-con side
HRS-CA002
HRS-CA003
The power supply cable can only be used for the applicable
models shown below. Do not use it for other products.
Approx. 3 m
Approx. 3 m
Approx. 3 m
Parts List
No. Description
q
Retaining clip
w
Holding screw
User's equipment side
User's equipment side
Approx. 100 mm
User's equipment side User's equipment side
