This manual provides the explanation of operation procedure to use the additional
function
of
Thermo-Chiller
communication). This manual should be used in addition to another operation
manual (HRX-OM-K003).
HRW002-H
HRW002-H1
HRW002-H2
HRW002-HS
HRW002-H1S
HRW002-H2S
Save This Manual Carefully for Use at Any Time
Operation Manual
THERMO CHILLER
HRW***
HRW***-**-D
HRW008-H
HRW008-H1
HRW008-H2
HRW008-HS
HRW008-H1S
HRW008-H2S
**-D
-
(optional
HRW015-H
HRW015-H1
HRW015-H2
HRW015-HS
HRW015-H1S
HRW015-H2S
© 2007 SMC CORPORATION All Rights Reserved
HRX-OM-K021-B
st
1
Edition: Sep 2006
rd
3
Edition: Dec 2007
model
of
DeviceNet
HRW030-H
HRW030-H1
HRW030-H2
HRW030-HS
HRW030-H1S
HRW030-H2S
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SMC Networks HRW D Series
Summary of Contents for SMC Networks HRW D Series
- Page 1 HRX-OM-K021-B Edition: Sep 2006 Edition: Dec 2007 Operation Manual THERMO CHILLER HRW*** **-D This manual provides the explanation of operation procedure to use the additional function Thermo-Chiller HRW***-**-D (optional model DeviceNet communication). This manual should be used in addition to another operation manual (HRX-OM-K003).
- Page 2 HRX-OM-K021 To the Customers Thank you for purchasing our THERMO CHILLER HRW Series (hereinafter called “This system”). For the long-term, safe use of this system, be sure to read and understand this manual in addition to another operation manual (HRX-OM-K003) thoroughly before performing operation of this system. This manual provides only the explanation of operation procedure to use the additional function of Thermo-Chiller HRW***-**-D (optional model of DeviceNet communication).
-
Page 3: Table Of Contents
HRX-OM-K021 Table of Contents Summary of HRW***-**D ..............1 .................... 1 EVICE ET COMMUNICATION Operation Screen ................2 ......................3 PERATION SCREEN 2.1.1 Menu screen 1.........................3 2.1.2 Mode Selection screen......................3 ......................4 YSTEM OPERATION HRW Series... -
Page 5: Summary Of Hrw***-**D
HRX-OM-K021 1. Summary of HRW***-**-D HRW***-**-D is a product that DeviceNet communication function is added to thermo chiller HRW series. And the DeviceNet communication can be used by selecting DeviceNet communication on communication mode setting. 1.1 DeviceNet communication Start / stop of this product, TEMP SP value setting, and start / stop of circulating fluid automatic recovery can be possible with DeviceNet communication. -
Page 6: Operation Screen
HRX-OM-K021 2. Operation screen This manual provides the explanation of operating procedure to use the DeviceNet communication. Selection of communication mode is conducted on “Mode Selection screen” shown in figure 2-1. Operating procedure for the others, please refer to the operation manual (HRX-OM-K002). Figure 2-1 Flow Chart of Operation Screen HRW Series... -
Page 7: Operation Screen
HRX-OM-K021 1.1 Operation screen 2.1.1 Menu screen 1 ＜ＭＥＮＵ＞ １．ＳＥＴＴＩＮＧ ２．ＲＥＭＯＴＥ／ＬＯＣＡＬ ３．ＩＮＩＴＩＡＬ ＳＥＴ Figure 2-2 Menu screen 1 Table 2-1 Menu screen 1 Item Descriptions Switches to the “Mode Selection screen” with the press of the REMOTE/LOCAL [ENT] key. 2.1.2 Mode Selection screen ＜ＲＥＭＯＴＥ／ＬＯＣＡＬ＞... -
Page 8: System Operation
HRX-OM-K021 2.1 System Operation Set the communicatiom mode to “DNET REMOTE”. Figure 2-4 Set the communication mode to “DNET REMOTE” Press the [SEL] key to display the ＜ＭＥＮＵ＞ ‘Menu screen 1”. １．ＳＥＴＴＩＮＧ ２．ＲＥＭＯＴＥ／ＬＯＣＡＬ ３．ＩＮＩＴＩＡＬ ＳＥＴ Figure 2-5 Menu screen 1 With the use of the arrow keys ([▲][▼]), ＜ＭＥＮＵ＞... - Page 9 HRX-OM-K021 Press the [ENT] key. The name of the current mode flashes. ＜ＲＥＭＯＴＥ／ＬＯＣＡＬ＞ ＭＯＤＥ： ＬＯＣＡＬ ＣＵＳＴＯＭ ＤＩＯ ＯＦＦ Figure 2-8 Mode Selection screen Use the arrow keys ([▲][▼]) to switch to “DNET REMOTE”. ＜ＲＥＭＯＴＥ／ＬＯＣＡＬ＞ ＭＯＤＥ：ＤＥＮＴ ＲＥＭＯＴＥ Ｉ ８ ０ １８ ＣＵＳＴＯＭ ＤＩＯ ＯＦＦ Figure 2-9 Mode Selection screen (“DNET REMOTE”) [Tips] To cancel a selection, press the [SEL] key, not [ENT] key.
