3.4.1 IO Function Definition

1. In the "Input Config 2" displaying window, it can set the input interface: Min1~Min4 & Ein1-8 & Ein 09~Ein16.
Input Interface
Min1 --, Shortcut1, Origin BTN, Test input-L, Test input-H
Min2 --, Shortcut 2, Stop BTN, Test input-L, Test input-H
--, Shortcut 3, Start BTN, Test input-L, Test input-H, Lack fault, Block fault, Temp fault,
Min3
Temp\Feed fault, Upper CS, Nether CS
Min4 --, Shortcut 4, Foot BTN, Test input-L, Test input-H
Ein1~Ein8 --, Shortcut 5-259
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Adj X-Limit,
Ein09
Shortcut 260, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Adj X-Limit,
Ein10
Shortcut 261, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Adj X-Limit,
Ein11
Shortcut 262, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Shortcut 263,
Ein12
Lack fault, Block fault, Temp fault, Temp\Feed fault, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Shortcut 264,
Ein13
Lack fault, Block fault, Temp fault, Temp\Feed fault, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Shortcut 265,
Ein14
Lack fault, Block fault, Temp fault, Temp\Feed fault, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Shortcut 266,
Ein15
Lack fault, Block fault, Temp fault, Temp\Feed fault, Upper CS, Nether CS
--, Origin BTN, Stop BTN, Start BTN, Foot BTN, Test input-L, Test input-H, Shortcut 267,
Ein16
Lack fault, Block fault, Temp fault, Temp\Feed fault, Upper CS, Nether CS
