Configuring VLAN
4.2
Configuring the PVID
Choose the menu VLAN > 802.1Q PVID Setting to load the following page.
Figure 4-2 Configuring 802.1Q PVID
Follow these steps to configure the PVID:
1) Select the ports and set the PVID for the ports.
PVID
2) Click Apply.
Note:
●
The PVID configuration will take effect only when 802.1Q VLAN mode is enabled.
●
You can specify a PVID only when the corresponding VLAN exists.
Set the PVID for the ports. The PVID ranges from 1 to 4094.
Configuring 802.1Q VLAN
User Guide
52
