Configuring PoE (Only for Certain Devices)
2) In the Port Config section, select the desired ports and specify the parameters . Click
Apply.
Ping IP Address
Startup Delay
Interval
Failure Threshold
Break Time
Failures
Reboots
Total Pings
Status
Enter the IP address of the PD connected to the port.
Ping IP Address should be the same as the connected PD's IP address.
Otherwise, the switch will continually reboot the PD.
Specify how long the switch waits for the connected PD's rebooting before the
switch starts to ping the PD's IP address.
Specify the interval between two consecutive ping packets.
Specify the threshold for ping failures.
If the switch fails to get the ping response from the PD on the port, the switch
will retry until the number of ping failures reaches the threshold, then the switch
reboots the PD.
Specify how soon the switch reboots the PD after the number of ping failures
reaches the threshold.
Display the number of ping failures since the latest reboot of the PD. It will be
reset when the PD responds to the ping packet or is rebooted.
Display the number of PD's reboots. It will be reset after reaching 9,999 or
when the switch is rebooted.
Display the total number of ping packets that the switch sends to the
connected PD. It will be reset after reaching 9,999 or when the switch is
rebooted.
Enable or disable PoE Auto Recovery on the desired ports. To make it enabled,
enable PoE Auto Recovery both globally and on the port.
Configuring PoE Auto Recovery
