Figure 3-2.
Annotated SAM4C32-EK Board Layout
RS232 Interface
RS485 Interface
Debug Interface
+
Power Supply
Power Supply
JTAG Interface
Zigbee Interface
Atmel SAM4C32
System Buttons
Atmel Custom LCD
User Buttons
XPRO Interface
Battery Coin Cell
PIO Extension
PIO Metering
PIO Extension
Extension
SAM4C32-EK [USER GUIDE]
