1. SAM4C32-EK Specifications
Table 1-1. SAM4C32-EK Specifications
Characteristic
PCB
PCB Material
Clock Speed
Ports
Memory
Board Supply Voltage
ROHS
CE and FCC Part 15 status
CAUTION
Electrostatic
sensitive
device
1.1 Battery
The SAM4C32-EK ships with a 3V coin battery. This battery is not required for the board to start up as long as
jumper JP8 is closed.
The coin battery is provided for user convenience in case the user would like to exercise the date and time backup
function of the SAM4C32 devices when the board is switched off.
1.2 Recovery Procedure
The demo software is stored in internal Flash memory. If the content of the internal Flash has been erased, it can
be reprogrammed recovered to the state as it was when shipped by Atmel using Atmel SAM-BA
Programmer available on the Atmel website (www.atmel.com). The binary file of the demo software is also
available on the Atmel website.
Specifications
6 layers, 140 mm x 100 mm
Standard FR4 in 1.6 mm thickness
Crystal 8 MHz
Piezoelectric Ceramic Resonator 8.192 MHz
32.768 kHz external clock
RS232
RS485
USB
TWI EEPROM
Serial Data Flash
5V DC from main connector power supply
5V DC from USB
3V Battery for Backup and RTC
Compliant
Compliant
ESD-Sensitive Electronic Equipment!
The SAM4C32-EK is shipped in a protective anti-static package. The board system
must not be subjected to high electrostatic discharge.
We strongly recommend using a grounding strap or similar ESD protective device when
handling the board in hostile ESD environments (offices with synthetic carpet, for
example). Avoid touching the component pins or any other metallic element on the
board.
SAM4C32-EK [USER GUIDE]
Atmel-11253A-ATARM-SAM4C32-EK-UserGuide_17-Sep-14
®
In-system
