ADCP-90-328 • Issue 2 • November 2005
Figure 11
15.0 IN.
(38.1 CM)
5.0 IN.
(12.7 CM)
8.7 IN.
(22.1 CM)
4.0 IN.
(10.2 CM)
2.25 IN.
(5.7 CM)
5.0 IN.
(12.7 CM)
Page 12
© 2005, ADC Telecommunications, Inc.
shows dimensions of the 144 position high density panel
Figure 11. Panel Dimensions (144 Position)
TOP VIEW
16.4 IN.
(41.7 CM)
21.9 IN.
(55.5 CM)
22.32 IN. (56.7 CM)
23-IN. RACK MOUNT (58.4 CM)
18.32 IN. (46.5 CM)
19-IN. RACK MOUNT (48.3 CM)
FRONT VIEW
17824-A
