ADCP-90-328 • Issue 2 • November 2005
Figure 9
shows dimensions of the 24 position 3RU panel.
12.0 IN.
(30.5 CM)
5.0 IN.
(12.7 CM)
4.0 IN.
(10.2 CM)
2.25 IN.
(5.7 CM)
5.0 IN.
(12.7 CM)
Page 10
© 2005, ADC Telecommunications, Inc.
23-IN. RACK MOUNT (58.4 CM)
19-IN. RACK MOUNT (48.3 CM)
Figure 9. Panel Dimensions (24 Position 3RU)
TOP VIEW
16.4 IN.
(41.7 CM)
21.9 IN.
(55.5 CM)
22.32 IN. (56.7 CM)
18.32 IN. (46.5 CM)
FRONT VIEW
17822-A
