Summary of Contents for Bernini M29866

  • Page 2 IMPORTANT BATTERY SAFETY INSTRUCTIONS, READ FIRST DANGER: Do not store battery in an airtight container, as it may cause an explosion. WARNING: When using electric devices, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and personal injury, including the following.
  • Page 3 splashes into eyes, immediately flush the eyes with plenty of clean water and consult a doctor. Sulfuric acid in the eyes may cause loss of eyesight and acid on the skin will cause burns. 9. Charge battery using the specified charger and under the charging conditions as specified.

  • Page 4: Table Of Contents

    Accessories Included with Your Fountain Assembling Your Fountain Step 1 : Large Bowl Assembly Step 2: Water Pump Assembly Step 3: Fountain Bowl Assembly Self-Watering Garden Instructions How The Self-Watering System Works Using The Garden Bowl Optional: Bubbling Decor Top Setting Up Your Fountain Filling Your Fountain Operating Your Fountain...
  • Page 6 This product comes with a one year limited warranty against materials and workmanship. Please review the list of accessories included with your new Bernini Fountain on the next page. Please note, images of parts are not to scale with one another.
  • Page 7 Fountain Bowl Base Large Bowl Garden Bowl with Rubber Attachment Tube Decor Top Battery Water Seal Water Pump Battery Battery Door Spacers Extension Charger Tube Single Seven Umbrella Six Stream Stream Stream Spray...

  • Page 8: Assembling Your Fountain

    Assembling Your Fountain Step 1 : Large Bowl Assembly Locate a flat, firm surface to place your fountain. Once you have found the perfect spot for your fountain, place the base upright in the desired area. Place the large bowl on top of the base. Note the bottom of the bowl has a locking key shape which matches the top of the base.

  • Page 9: Step 2: Water Pump Assembly

    Step 2: Water Pump Assembly Feed the cable on the water pump down into the pipe in the middle of the large bowl. Make sure to feed as much of the cable as possible down into the pipe. Slip the foam water seal onto the power cord of the water pump.

  • Page 10: Step 3: Fountain Bowl Assembly

    For convenience, lay the fountain bowl on its side inside the large bowl to make connecting the water pump to the tube inside the fountain bowl easier. Slide the extruded outlet of the water pump into the tube inside the fountain bowl. Push the outlet into the tube until the connection is snug.
  • Page 11 Step 4: Connect Battery The battery included with your Bernini Fountain comes pre-charged, so you do not have to charge the battery before you use your fountain for the first time Before connecting the battery to your fountain, insert the water-tight plug attached to the battery into the receptacle labelled with a black circle.

  • Page 12: Self-Watering Garden Instructions

    Self-Watering Garden Instructions The following instructions are for users that would like to use the gardening feature. 1 . Transplant potted plant into the Garden Bowl. 2. Before placing the Garden Bowl onto the fountain make sure any loose soil is cleaned from the bottom of the bowl to reduce dirt in the fountain for first use.

  • Page 13: How The Self-Watering System Works 1

    Using Garden Bowl Your self watering aerating garden fountain is designed to adjust for different types of plants depending on their water requirements. There are four water levels depending on the water requirements of your particular plant. These are adjusted by placing the Rubber Spacers in between the Fountain Bowl and the Garden Bowl.
  • Page 14 Dancing Water Feature Assembly If you would like to have a dazzling fountain pattern adorning the top of your fountain you can use the included fountain spout assemblies to create an eye-catching fountain show. Make sure the end of the feeder tube is pressed snuggly into the middle of the fountain bowl.
  • Page 15 Optional: Bubbling Decor Top Instructions Remove the garden bowl or dancing water feature spout. Detach the fountain bowl from the large bowl. Disconnect the water pump from the feeder tube and then remove the feeder tube from the fountain bowl. Insert the decor top's water tube into the middle of the fountain bowl.

  • Page 16: Setting Up Your Fountain

    3 seconds. Auto Function Your Bernini Fountain can run in four different automatic modes of operation. To access these functions the fountain must be powered off. One hour operation: Press the power button once and your fountain will automatically turn off after one hour of operation.

  • Page 17: Recharging Your Fountain S Battery 1

    Recharging Your Fountain s Battery Before proceeding, please read Warnings and Important Information on page 1 . Plug the battery charger into an electrical wall outlet. Plug the cord running from the battery charger to the black labeled receptor on the rechargeable battery.

  • Page 18: Adjusting Water Pump Power 1

    Cleaning the Water Pump Impeller Sometimes the impeller (labelled “B” in the diagram below) will need to be cleaned. To service this part remove the impeller cover (labelled part “A” in the diagram below) and then remove the impeller from the Water Pump.
  • Page 19 Priming The Water Pump 1 . If the Garden Bowl is on top of the fountain, remove the Garden Bowl. 2. Remove the fountain bowl by turning the bowl a quarter turn counter- clockwise and then lift. You can now rest the fountain bowl on its side. 3.

  • Page 20: Faq 1

    Frequently asked questions about our fountains. Will my fountain fall down in heavy winds? If you live in a region with heavy winds, you can add weight to the base of your fountain by adding sand to the chamber in the bottom of the base.

  • Page 21: Troubleshooting

    Water is not pouring from all of the spouts on the edge of the fountain bowl: To ensure that water flows evenly from the fountain bowl on your Bernini Fountain, make sure to place your fountain on a flat and sturdy surface.
