Summary of Contents for Bernini Murano
- Page 3 This product comes with a six (6) month limited warranty against materials and workmanship. Please review the list of accessories included with your Bernini™ Fountain on the next page. Please note, images of parts are not to scale with one another.
-
Page 4: Table Of Contents
CONTENTS Step1: Base & Bowl Bowl Locking System Step2: Base & Light/Pump Tier Installing The LED Light Ring Connecting The Water Pump Installing The Light/Pump Tier Fill Your Fountain Step 3: Fountain Glass Globe Installation Step 4: Battery Installation Connecting The Battery Inserting The Battery Compartment Door Removing The Battery Compartment Door Step 5: Setting Up Your Fountain... - Page 5 Parts for your Parts for Your Bernini™ Fountain Bernini Fountain: ™ Glass Globe Light/Pump Tier Water Pump LED Light Ring Battery Charger Assembly Bowl Battery Rechargeable Compartment Connection Leveling Shim Battery Door Port Base...
-
Page 6: Step1: Base & Bowl
Step 1: Base & Bowl You will need: Bowl Base Remember if you need help contact Customer Care: 0203 617 1773... -
Page 7: Bowl Locking System
Bowl Locking System A look at how the bowl locking works on your Fountain. Top of base Bottom of the bowl Note: You will notice that there are two different sized tabs on the bottom of the bowl and there are two corresponding grooves in the top of the base. These tabs fit together and lock when turned clockwise. - Page 8 Bowl Locking System (Continued) At this point, your fountain should look like the image on the left. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 0203 617 1773...
-
Page 9: Step2: Base & Light/Pump Tier
Step 2: Base & Light/ Pump Tier Assembly You will need: Light/Pump Tier LED Light Ring Bowl and Base Water Pump Assembly Assembly Remember if you need help contact Customer Care: 0203 617 1773... -
Page 10: Installing The Led Light Ring
Installing The LED Light Ring Set the Light/Pump Tier on a level sturdy surface for assembly. Step 1: Find the LED Light Ring cord with the In this step you will install the LED Light Ring green plug and feed into the top of the Light/ into the Light/Pump Tier. -
Page 11: Connecting The Water Pump
Connecting The Water Pump Step 1: Grasp the Water Pump in one hand and, with the other hand grasp the hose that goes to the top of the Light/Pump Tier. Push the hose onto the discharge nipple on the discharge side of the water pump. If this step proves difficult apply a twisting motion while pushing together. - Page 12 Installing The Light/Pump Tier (Continued) Step 2: Firmly press the plug into the pipe in the Step 1: The Light/Pump Tier has 2 cords, one middle of the bowl. attached to the pump and one attached to the Colored LED Lights. Feed the black cord and If you are having trouble pressing the plug into the the green cord down into the pipe.
-
Page 13: Fill Your Fountain
At this point, your fountain should look like the image on the left. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 0203 617 1773... -
Page 14: Step 3: Fountain Glass Globe Installation
Step 3: Fountain Glass Globe Installation You will need: Glass Globe Assembled Base Remember if you need help contact Customer Care: 0203 617 1773... - Page 15 Fountain Glass Globe Installation Top of Light/Pump Tier Bottom of Glass Globe Note: You will notice that there are two different sized tabs on the bottom of the Glass Globe and there are two corresponding grooves in the top of the Light/Pump Tier. These tabs fit together and lock when turned clockwise.
- Page 16 Fountain Glass Globe Installation (Continued) At this point, your fountain should look like the image on the left. Go to the next page for the next step to setup your new Bernini™ Fountain. Remember if you need help contact Customer Care: 0203 617 1773...
-
Page 17: Step 4: Battery Installation
Step 4: Battery Installation You will need: Connection Port Rechargeable Battery Fountain Battery Compartment Assembled Door Remember if you need help contact Customer Care: 0203 617 1773... -
Page 18: Connecting The Battery
Connecting The Battery Step 1: In the open battery Step 2: Using the cords from Step 3: Place your connection compartment, you will see three inside the base and the cord port inside the designated angled cords hanging down that you from the battery, connect the area located at the back of your must connect to the connection... -
Page 19: Inserting The Battery Compartment Door
This is for the optional Bernini™ solar panel cord. Removing The Battery Compartment Door Step 1: Carefully remove Step 2: Then, pull the battery DO NOT OVEREXTEND THE... -
Page 20: Step 5: Setting Up Your Fountain
Step 5: Setting Up Your Fountain You will need: Fountain Assembled Remember if you need help contact Customer Care: 0203 617 1773... -
Page 21: Operating Your Fountain
The on-board control panel is located near the top of the base, just below the small built-in bowl. See the diagram below to see how the all-new on-board controls work for your Bernini™ Fountain. IF YOUR FOUNTAIN IS MAKING A LOUD NOISE, DON’T PANIC! This just means that there are air bubbles stuck in the water pump. - Page 22 Operating Your Fountain ( Continued) BUTTON DESCRIPTION This function is the same as the 1-4 Hour Timer (button A) except with the added feature of automatically turning your fountain on at the same time the next day for the interval you selected. One hour operation: press the B button once for your fountain to turn on with an automatic shut-off after one hour of operation.
- Page 23 Operating Your Fountain ( Continued) You can now try your Bernini™ fountain to see if everything is working correctly! Turn your fountain on and you should see water flowing from around the Glass Globe on top of the Light/Pump Tier. If water is not flowing, please refer to the “Try Priming The Water Pump”...
-
Page 24: Troubleshooting And Maintenance
To clean your fountain, drain of all water and disassemble. Use a mild soap and a soft cloth to clean the parts of your Bernini™ Fountain. Your fountain bowl and Light/Pump Tier will form a natural patina finish which with time may appear lighter or whiter than the original color. -
Page 25: Cleaning The Water Pumps' Parts
After about six weeks of usage, you may want to clean the water pump’s filter and impeller to keep your Bernini™ Fountain in tip-top shape. You will need to drain your fountain of all water prior to cleaning the water pumps’ parts. -
Page 26: Priming The Water Pump
Is your fountain making a loud noise or do you not see water flowing? Try Priming The Water Pump If you find the water pump is running, but water is not flowing from your fountain, or you hear a loud grinding noise coming from your fountain, not to worry, you can try priming the water pump: Begin by turning your fountain off. -
Page 27: Using Leveling Shims
Using Leveling Shims If you are having trouble getting water to flow evenly off of the spouts on your Bernini™ Fountain, you may need to level the surface that your fountain is placed on. With the included leveling shims, you do not need to move your fountain, just follow the instructions below to get even water flow. -
Page 28: Water Pump's Connection
Water Pump Connection If your Bernini™ Fountain did not come with the water pump already connected to the tube inside of the fountain tier or if the water pump gets disconnected from the fountain tier, use these instructions to reconnect your water pump. - Page 29 IMPORTANT BATTERY SAFETY INSTRUCTIONS DANGER: Do not store battery in an airtight container as it may cause an explosion. WARNING: When using electric devices, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following: WARNING: 1.
- Page 31 (6) months from the date of original purchase. If within six (6) months this product fails due to defect in material or workmanship, Bernini will repair, replace or supply any defective part at their option. The purchaser must contact Bernini and provide a description of the defective part, including digital pictures if requested, with this original purchase documentation as validation of warranty coverage.
- Page 32 Facebook: berninifountains Twitter: @yrdllc © Yeiser Research & Development, LLC; 2016. All rights reserved. Bernini Fountain Company UK, Suite 114, 315 High Road Chiswick London W4 4HH United Kingdom Distributed by: QVC London Building 8 Chiswick Park 566 Chiswick High Road...
