Bernini Marcelli BL83052 Instructions

Assembly Instructions

Read instructions carefully and DO NOT plug in fountain until assembly is complete.
Notes:
• Choose an appropriate location for the fountain.
• Excessive weight or pressure on any of the fountain sections may cause it to fall. Keep pets, children, or
anyone from sitting, leaning, or climbing on any of the fountain components.
• While fountain is designed to operate as splash free as possible, some water splashing out of the fountain
is inevitable. Place the fountain in a location where any splashing will not cause damage.
• The National Electric Code requires that a ground fault circuit interrupter (GFCI) be used in the branch
circuit supplying fountain pump and other pond equipment. Seek your electrical supplies dealer for this
device.
• Keep the fountain always works with sufficient water and clean of debris and dirt to ensure proper
functioning of the pump.
• Clean your fountain with a soft cloth and change the water when necessary. Due to water evaporation,
you may see a buildup of white residue on the fountain surface from mineral content in the water supply.
To prevent such buildup, clean your fountain with damp cloth. Do not use any abrasive or chemicals to
clean as they may ruin the finish.
• See the pump instructions for pump safety, maintenance, and warranty information.
• Keep this manual for future reference.
Installation & Assembly:
• Place the fountain on a level surface, away from areas where it is likely to get clogged with leaves and
make sure that the cable will reach the socket.
• Follow steps to assemble as below illustration marks.
Figure'1-5'
Step (1) Connect the big plate and pedestal tightly as arrowheads indicates.
Figure'2-5'
Step (2) Get the wire of pump through plastic pipe of big plate centre. Make sure the wire put into the
pedestal's cavity.
Step (3) Connect the pillar and big plate tightly as arrowheads indicates.
Figure'3-5'
Step (4) Connect medium plate and pillar tightly as arrowheads indicates.
Figure'4-5'
Step (5) Put plastic hose into the plastic pipe of medium plate centre then connect top part and medium plate
tightly as arrowheads indicate.
Figure'5-5'
Step (6) Connect plastic hose to pump outlet.
Step (7) Please close the small door to the pillar of big plate centre.
Step (8) and (9) Fill the big plate with enough clean water to assure the pump to work properly. Plug the pump,
water will start to flow in a minutes.
• Adjust the pump flow rate to achieve the desired effect and to minimize any splashing. Splashing can
occur if the flow rate is too high or the reservoir is too full. The flow rate can be increased or decreased
by moving the flow rate control slider on the pump body. Moving the switch towards '+/ Max.' will increase
the flow rate and moving it towards '-/Min' will decrease it. On some type of pumps, flow regulator may
be turned clockwise or anticlockwise to adjust.
* * WARNING * *
Marcelli Fountain Instructions
www.berninifountains.com
BL83052
