Bernini BARI Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BA RI FOUN TA IN
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BARI and is the answer not in the manual?

Questions and answers

Related Manuals for Bernini BARI

Summary of Contents for Bernini BARI

  • Page 1 BA RI FOUN TA IN Owner’s Manual...

  • Page 2: Product Registration

    Via Phone: call our customer care department at 1+ (619) 449-2392 Via email: customercare@berninifountains.com Failure to register your fountain will not diminish your warranty rights. However, registering your fountain will allow Bernini Fountains to better serve you with any of your customer care needs.
  • Page 3 Bari is highly multifaceted city, known as the “Gateway to the East” due to its long tradition of trade, this capital of Apulia is rich in history. There is the famous Bari promenade, one of the most beautiful in Italy, overlooking the clear sea and the unique charm of Bari.
  • Page 4 PARTS For Your Bernini Fountain ™ Shower Umbrella Dancing Water Attachments Top Tier Topper Battery Compartment, Water Tube & Water Pump Large Bowl Upper Base Leveling Shim Lower Base Items/Tools Required: (Not Included) . Philips Screwdriver Base . 4 D Cell Batteries...

  • Page 5: Table Of Contents

    CONTENTS PAGE STEP 1: BASE & LARGE BOWL ............1 Base Assembly Locking System ..............2 Base & Bowl Locking System ................3 STEP 2: TOPPER INSTALLATION............4 Installing The Topper ....................5 STEP 3: BATTERY INSTALLATION ............6 Inserting Batteries Into The Battery Compartment .......7 Assembling Battery Compartment Housing &...

  • Page 6: Step 1: Base & Large Bowl

    STEP 1 BASE & LARGE BOWL You will need: Upper Base, Large Bowl Lower Base & Base Foot If you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 7: Base Assembly Locking System

    BASE ASSEMBLY LOCKING SYSTEM Assembling the sections of the base. Top of the Base Foot Bottom of the Base Note: There are threads on the top of the Base Foot and there are corresponding threads on the Bottom of the Lower Base. These threads fit together securely when tightened.

  • Page 8: Base & Bowl Locking System

    BASE & BOWL LOCKING SYSTEM A look at how the base & bowl locking system works on your Fountain. Note: There are threads on the bottom of the Large Bowl and there are corresponding threads on the top of the Base. These threads fit together securely when tightened. STEP 1.5 Align and STEP 1.6 Turn the Large STEP 1.4 Place the...

  • Page 9: Step 2: Topper Installation

    STEP 2 TOPPER INSTALLATION You will need: Assembled Topper Base & Large Bowl If you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 10: Installing The Topper

    INSTALLING THE TOPPER Inside of the Large Bowl Bottom of the Topper Note: Just as you installed the Large Bowl to the Base, you will notice that there are threads in the Bowl and there are corresponding threads on the bottom of the Topper.

  • Page 11: Step 3: Battery Installation

    STEP 3 BATTERY INSTALLATION You will need: Items/Tools Required: (Not Included) . Philips Screwdriver . 4 D Cell Batteries Fountain Battery Compartment Assembled Water Tube & Water Pump If you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 12: Inserting Batteries Into The Battery Compartment

    INSERTING BATTERIES INTO THE BATTERY COMPARTMENT STEP 3.1 Unscrew (counter clockwise) the Battery Compartment Screws and open cover. Note: Cover fits tightly and may take some effort to separate. If screws continue to turn compartment is completely unscrewed. STEP 3.2 Fountain requires 4 D batteries (Not Included). Insert x2 D Batteries with the (+) side facing up in Battery Compartment and x2 D Batteries with the (-) facing up in Battery Compartment.

  • Page 13: Assembling Battery Compartment Housing & Battery Cover

    ASSEMBLING BATTERY COMPARTMENT HOUSING & COVER Locating Dowel STEP 3.3 Reinstall the Fountain Top by aligning the locating dowel in the Battery Compartment and Fountain Top. Set the Battery Cover down onto the Battery Compartment ensuring the dowel sets into the alignment hole.
  • Page 14 ASSEMBLING BATTERY COMPARTMENT HOUSING & COVER STEP 3.4 Apply pressure and tighten the Battery Cover Screws by turning clockwise. NOTE: Pressure must be applied to the Battery Compartment while tightening the screws to assure the compartment is properly sealed. After both screws have been tightened, you may notice a small gap between the Battery Cover and the Battery Compartment Housing.

  • Page 15: Assembling Water Pump & Tube To Battery Compartment

    ASSEMBLING THE WATER PUMP & TUBE TO BATTERY COMPARTMENT Figure B Figure A STEP 3.5 Connect one side of the Water Tube to the Water Pump and the other end of the tube to the bottom side of the Battery Compartment (Figure A). STEP 3.6 Lower the Battery Compartment and Water Pump into the Topper.

  • Page 16: Step 4: Setting Up Your Fountain

    STEP 4 SETTING UP YOUR FOUNTAIN You will need: WATER TO FILL YOUR FOUNTAIN Shower Umbrella Pirouette Dancing Water Fountain Attachments Assembled If you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 17: Fill Your Fountain

    FILL YOUR FOUNTAIN • Fill the large bowl until the water is 1 inch (2.5 centimeters) from the top of the bowl. • To dislodge any air bubbles from the pump, grab both sides of the large bowl and quickly shake your fountain for ten seconds. •...
  • Page 18 OPERATING YOUR FOUNTAIN (CONTINUED) Programing The Fountain: • Press the A Button 2 times: Clears out all programing. • Press the B Button 1 time: Will program the fountain to run for 1 hour each day at the same time. The light (Figure C), will flash once to confirm your selection.

  • Page 19: Dancing Water Attachments

    DANCING WATER ATTACHMENTS Figure D Shower Pirouette Umbrella Figure E Figure F DANCING WATER ATTACHMENTS: (OPTIONAL) You can put any of the Dancing Water Attachments on the Fountain whether the Fountain is running or is not running. • Select one of the Dancing Water Attachments and place on the outlet in the middle of the Battery Compartment (Figure D, E, &...

  • Page 20: Step 5: Fountain Configurations

    STEP 5 FOUNTAIN CONFIGURATIONS You will need: Upper Base Lower Base Large Bowl Topper Base Foot If you need help contact Customer Care: 1+ (619) 449-2392...

  • Page 21: Fountain Configurations

    FOUNTAIN CONFIGURATIONS There are 5 different looks the Bari Fountain can be configured in, (1 configuration is covered under Step 2 the other 4 are configured in this Step 5 ): 1. BASE FOOT/LOWER BASE PLANTER CONFIGURATION What you will need for this configuration...
  • Page 22 3. TABLE TOP FOUNTAIN CONFIGURATION What you will need for this configuration Topper Large Bowl STEP 5.1 Align and connect the STEP 5.2 Turn the threads and turn clockwise Topper to the bowl. to screw the Large Bowl and Topper together. At this point, your fountain should look like this.

  • Page 23: Full Fountain With-Out Lower Base Configuration

    4. FULL FOUNTAIN WITH-OUT LOWER BASE CONFIGURATION What you will need for this configuration Upper Base Topper Large Bowl Base Foot STEP 5.3 Align and set STEP 5.4 Set the large Bowl STEP 5.5 Align and connect onto the Upper Base and the Upper Base onto the Topper to the bowl.

  • Page 24: Troubleshooting And Maintenance

    TROUBLESHOOTING AND MAINTENANCE WATER PUMP CONNECTION If your fountains water pump tube becomes disconnected from pump and or Bat- tery Compartment use these instructions to reconnect your water pump. Step 2: Rest the Battery and Pump As- Before beginning, remove the Battery sembly on its side.

  • Page 25: Priming The Water Pump

    PRIMING THE WATER PUMP If you find the Water Pump is running, but water is not flowing from your Fountain, you can try priming the Water Pump: • Turn off Fountain: Grab both sides of the Fountain and quickly shake your Fountain for ten seconds.

  • Page 26: Cleaning Your Water Pump's Parts

    CLEANING YOUR FOUNTAIN (CONTINUED) • To clean your fountain, drain of all water and disassemble • Use a mild soap and a soft cloth to clean the parts of your fountain. • DO NOT SCRUB YOUR FOUNTAIN, THIS COULD CAUSE DAMAGE TO THE FINISH OF YOUR FOUNTAIN.

  • Page 27: Cold Storage

    CLEANING YOUR WATER PUMP IMPELLER (CONTINUED) Step 3: Remove the impeller from Step 4: Rinse the impeller and the its chamber. impeller chamber until all debris has been removed. Reassembly is the reverse of disassembly. • Replace the impeller in the impeller chamber. •...

  • Page 28: Troubleshooting Checklist

    TROUBLESHOOTING CHECKLIST PROBLEM SOLUTION Fountain is Check that batteries have brand new batteries: (See not working Changing Battery Section). Prime Pump as instructed. (Refer to Priming The Water Pump). Check batteries are installed correctly: (See Installing Battery Section). Check that batteries have a full charge: (See Changing Water Not Battery Section).

  • Page 29: Limited One-Year Warranty

    Bernini will repair, replace or supply any defective ™ part at their discretion. The purchaser must contact Bernini and provide a description ™ of the defective part, including digital pictures if requested, with this original purchase documentation as validation of warranty coverage.

  • Page 30: Battery Safety

    BATTERY SAFETY IMPORTANT BATTERY SAFETY INSTRUCTIONS DANGER: Do not store battery in an airtight container as it may cause an explosion. WARNING: When using electric devices, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following: 1.
  • Page 31 If you need help contact Customer Care: 1+ (619) 449-2392...
  • Page 32 THANK YOU FOR SELECTING BERNINI FOUNTAINS Were excited to offer you the highest quality fountains with the reliability you need! We would love to hear if you have any suggestions or ideas that can be incorporated into new or enhanced features. We hope you have many years of enjoyment from your fountain and we look forward to hearing from you.
