Summary of Contents for Bernini 6-in-1 Torri Fountain
- Page 2 This product comes with a one year limited warranty against materials and workmanship. Please review the list of accessories included with your Bernini™ Fountain on the next page. Please note, images of parts are not to scale with one another. About Torri: Torri is a medieval village in Italy that sits right next to the Mediterranean Sea and French border.
- Page 3 Parts to your new Bernini Fountain: ™ Infinity Bowl/Planter 3 Prong Foot /Bird Feeder Torri Topper Large Bowl Dancing Water Attachments Battery Compartment, Leveling Shim Water Tube & Water Pump Base...
-
Page 4: Table Of Contents
CONTENTS Step 1: Base & Large Bowl Bowl & Base Locking System Step 2: Torri Topper Installation Installing The Torri Topper Step 3: Battery Installation Inserting Batteries Into The Battery Compartment Installing Batteries Assembly Of Battery Compartment Housing & Battery Cover Assembly Of Water Pump &... -
Page 5: Step 1: Base & Large Bowl
Step 1: Step 1: Base & Large Bowl You will need: Large Bowl Base Remember if you need help contact Customer Care: 1+ (619) 449-2392... - Page 6 Base & Bowl Locking System A look at how the base & bowl locking system works on your Fountain. Bottom of Large Bowl Top of Base Note: You will notice that there are two different sized tabs on the bottom of the Large Bowl and there are two corresponding grooves in the top of the Base.
-
Page 7: Step 2: Torri Topper Installation
Step 1: Step 2: Torri Topper Installation You will need: Torri Assembled Base & Topper Large Bowl Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 8: Installing The Torri Topper
Installing The Torri Topper Step 1: Like the Large Bowl and Base, the Torri Top- per uses a key-lock system to connect to the Large Bowl. The square notches in the groove of the Large Bowl will align with the square gaps in the bottom of the Torri Topper. -
Page 9: Step 3: Battery Installation
Step 1: Step 3: Battery Installation You will need: Battery Compart- Fountain ment, Water Tube Assembled & Water Pump Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 10: Inserting Batteries Into The Battery Compartment
Inserting Batteries Into The Battery Compartment Battery Compartment Retaining Figure 1c Screws X2 Figure 1a Figure 1b Installing Batteries: 1. (If Battery Compartment & Water Pump are installed into the Topper) Lift out of the Topper (Figure 1a). Disconnect the Water Tube from the Battery Compartment (A Figure 3a). 2. -
Page 11: Assembly Of Battery Compartment Housing & Battery Cover
Assembly Of Battery Compartment Housing & Cover: 1. Place Battery Cover on Battery Compartment Housing. Turn over assembled Battery unit and place on a flat, level surface. Using a Phillips screwdriver (not included) first, tighten left screw down firmly. 2. After tightening the left screw, you will notice a small gap between the Battery Cover and the Battery Compartment Housing. -
Page 12: Changing Batteries
Changing Batteries: 1. Remove any Dancing Water Attachment, lift Battery Compartment and Water Pump out of the Fountain (Figure 4a). Ensure Battery Compartment and Water Pump are completely dry before opening Battery Compartment. It is important that no water enters the Battery Compartment. -
Page 13: Step 4: Setting Up Your Fountain
Step 1: Step 4: Setting Up Your Fountain You will need: Water To Fill Your Fountain Fountain Dancing Water Assembled Attachments Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 14: Fill Your Fountain
Fill Your Fountain After you have picked the container you want your fountain in, fill the container so that the water is about 1 inch (2.5 centimeters) and/or covers the pump. Next, After you have filled your fountain, to dislodge any air bubbles from the pump, grab both sides of the large bowl and quickly shake your fountain for ten seconds. -
Page 15: Dancing Water Attachments
You can now try your Bernini™ Fountain to see if everything is working correctly! Turn your fountain on and you should see water flowing from the STOP! outlet on the top of the Torri Topper. -
Page 16: Step 5: 3-In-1 Infinity Bowl/Bird Feeder/Planter Bowl
Step 1: Step 5: 3-in-1 Infinity Bowl/ Bird Feeder/ Planter Bowl You will need: Infinity Bowl/Planter 3 Prong Foot /Bird Feeder Remember if you need help contact Customer Care: 1+ (619) 449-2392... -
Page 17: How The Self-Watering System Works
REMOVE REMOVE INSTALL INSTALL Figure 1 Figure 2 Figure 3 Infinity Bowl To install the Bowl as an Infinity Pool, take the Bowl and the Cap, screw the Cap into the inside of the bowl turning clockwise (Figure 1, 2 & 3). Do not over tighten. -
Page 18: Planter
BIRD FEEDER PLANTER Figure 7 Figure 8 Planter To install the Bowl as a Planter, take the Bowl and 3 Prong Foot, line up the arrows (Figure 11 white circle) on the 3 Prong Foot to the “Planter” position located on the bottom of the bowl (Figure 8). -
Page 19: Bird Feeder
Figure 9 Figure 10 Bird Feeder To install the bird feeder, take the Infinity bowl and 3 prong foot, line up the arrows (Figure 11 white circle) on the 3 prong foot to the bird feeder position located on the bottom of the bowl (Figure 9 &... -
Page 20: Troubleshooting And Maintenance
After about six weeks of usage, you may want to clean the water pump’s impeller to keep your Bernini™ Fountain in tip-top shape. You will need to drain your fountain of all water prior to clean- ing the water pumps’ parts. -
Page 21: Priming The Water Pump
Priming The Water Pump If you find the Water Pump is running, but water is not flowing from your Fountain, you can try priming the Water Pump: Turn off Fountain, grab both sides of the Fountain and quickly shake your Fountain for ten seconds. This is to dislodge any air bubbles that may be caught in your Water Pump. -
Page 22: Troubleshooting Guide
Troubleshooting Guide PROBLEM SOLUTION Fountain is not Check that batteries have a full charge: See Changing Battery Section. working Pump Check that batteries have a full charge: See Changing Battery Section. not working Prime Pump as instructed. (Refer to priming the water pump) Add Water Check to see that pump tubes are connected Check to see that the pump and pump tubes are clear of debris. - Page 23 (1) year from the date of original purchase. If within one (1) year this product fails due to defect in material or workmanship, Bernini™ will repair, replace or supply any defective part at their discretion. The purchaser must contact Bernini™ and provide a description of the defective part, including digital pictures if requested, with this original purchase documentation as validation of warranty coverage.
- Page 24 Santee, California 92071 World Wide Patents Pending Email: customercare@berninifountains.com On the web: www.berninifountains.com Facebook & Pinterest: Bernini Fountain Company Instagram:@berninifountains Twitter: @yrdllc © Yeiser Research & Development, LLC; 2021. All rights reserved. Made in China 001248 BIO6IOTMFI rev 2d us...
