Z8F04A08100KIT Development Kit
User Manual
12

USER DEBUG Mode Jumper Settings

Switches S1, S2, and SW1

External Interface Headers JP1 and JP2

Development Board
J3 1-2
J4 OUT
J5 1-2
J6 1-2
J7 OUT
J8 1-2
J9 1-2
J10 1-2
J11 OUT
When running the board in USER DEBUG mode, the following jumpers
MUST be set:
J3 OUT
J4 IN
J6 OUT
J7 IN
Switches S1, S2, and SW1 on the Z8 Encore! XP™ 4K Series 8-Pin
Development board perform the following functions:
S1 – Test switch
S2 – Power ON/OFF switch
SW1 – RESET
External interface headers JP1 and JP2 are shown in the schematic on
page 15.
UM018702-0505
