For further information on the Z8 Encore!
product specification, P/N PS0228, available for download from
www.zilog.com.

UART with IrDA Endec

The Z8 Encore! XP 4K Series 8-pin MCU (component U5) contains a
fully-functional, high-performance UART with Infrared Encoder/Decoder
(ENDEC). The Infrared ENDEC is integrated with an on-chip UART
allowing easy communication between the Z8 Encore! XP™ 4K Series 8-
pin MCU and IrDA transceivers. Infrared communication provides
secure, reliable, low-cost, point-to-point communication between PCs,
PDAs, cell phones, printers and other infrared enabled devices.
UM018702-0505
1KB register RAM
5-channel, 10-bit analog-to-digital converter (ADC)
Full-duplex UART
Infrared Data Association (IrDA)-compliant infrared encoder/decoder
Two 16-bit timers with capture, compare, and PWM capability
Watch-Dog Timer (WDT) with internal RC oscillator
Six I/O pins
Programmable priority interrupts
On-Chip Debugger
Voltage Brown-out Protection (VBO)
Power-On Reset (POR)
2.7–3.6 V operating voltage with 5V-tolerant inputs
Operating temperatures: 20° ±10° C
Z8F04A08100KIT Development Kit
®
family of devices, consult the
Development Board
User Manual
