9. Technical Specification

ANALOG
• Analog Inputs Connectors: 2 XLR / TRS balanced. TRS inputs accessible from
both back and front panels.
• Resolution AD: PCM 32bit / DSD up to 256 (11.2 Mhz)
• PCM Sample Rate: 44,1 / 48 / 88,2 / 96 / 176,4 / 192 / 384 Khz
• Transparent line level (electronic) or passive nickel transformer with saturation control
DIGITAL
• Computer Audio I/O: 2.0 Hi-Speed, data stream up to 480Mbits/384kHz, Type B, driverless.
• AES/EBU Output: XLR, PCM 24Bits / up to 384 kHz, DSD up to x128 (DoP)
• TOSLINK Optical Output: PCM up to 192kHz single wire, DSD x64 (DoP)
• S/PDIF Coaxial Output: PCM up to 384kHz single wire, DSD up to x128 (DoP)
• SDIF DSD Output: DSD x64, x128, x256
• WordClock I/O: BNC, 75 Ohm
• Clock: <1ps jitter Mytek Femtoclock (tm) generator.
GENERAL
• Firmware: upgradable via USB Control panel, updates available online, periodic feature upgrades
• MQA Kernel(tm) Built in (MQA compliant filters and dithering)
• Power Supply: Worldwide 30W power supply 100-240V 50/60 Hz.
• Optional 12VDC power input (2.5mm, inner +)
• External power supply input: 12VDC, 4 - 6A / (inner pin +)
• External power supply connector dimensions: 5,5 mm / 2,5 mm (inner pin)
• Dimensions [W x H x D]: 8.5" x 8.5" x 1U / 218 x 44 x 206 mm / 1U half rack
• Weight: 4 lbs (2kg)
