2. Package Content

• The Brooklyn ADC (black or silver)
• USB 2.0 Cable
• Power cord
• Owner's manual

3. Features

• Conversion: up to 384k, true 32bit PCM recording possible (DXD)
• Native DSD recording up to DSD256, DoP recording up to DSD 128 with future Quad DoP for DSD
256
• dual mono ADC chipsets with fully balanced signal path
• high definition metering with simultaneous RMS and PEAK indication
• built-in passive nickel transformers
• 130dB Dynamic Range
• headroom: 13 - 20
Analog Inputs:
• combo XLR / TRS at the rear panel and TRS at the front panel
• accept balanced and unbalanced sound sources (switchable in menu)
• built-in passive nickel transformers with saturation control
Digital outputs:
Four digital outputs are fitted (1x AES/EBU, 1x S/PDIF, 1 SDIF, 1x TOSLINK) which allow a wide
of digital devices to be connected.
• AES/EBU - PCM up to 192 kHz or 384 kHz if connected to Brooklyn DAC+, DSD up to x64 or x128
if connected to Brooklyn Dac+ (DoP)
• S/PDIF - PCM up to 192 kHz or 384 kHz if connected to Brooklyn DAC+, DSD up to x64 or x128
if connected to Brooklyn Dac+ (DoP)
• SDIF3 DSD - up to DSD256
• TOSLINK - PCM up to 192 kHz, DSD up to x64 (DoP)
• USB (Mytek proprietary USB 2.0 Class 2) – PCM 32bit / 384 kHz, DSD x256, llows to send digital
data to AES, SPDIF, Toslink amd SDIF outputs.
Mytek Brooklyn ADC
range
