5.2 Connection of the power supply
The pump must be protected on-site (min. 10 A, slow) and must be connected to an
external mains switch. All cables used must have a heat resistance of up to 85 °C.
They must not be in contact with the pipe or the pump and motor casing.
All cables must be connected in accordance with EN 60204-1 and EN 50174-2: 2000.
The electrical connection must be made as indicated on the nameplate.
ModulA...
ModulA 25-4 180
ModulA 25-6 180
ModulA 25-8 180
ModulA 25-10 180
ModulA 25-12 180
ModulA 32-4 170
ModulA 32-6 170
ModulA 32-8 170
ModulA 32-10 170
ModulA 32-12 170
ModulA 32-4 180
ModulA 32-6 180, ModulA-D 32-6 180
ModulA 32-8 180, ModulA-D 32-8 180
ModulA 32-10 180
ModulA 32-12 180
ModulA 32F-6 220, ModulA-D 32F-6 220
ModulA 40-4 220
ModulA 40-6 220, ModulA-D 40-6 220
ModulA 40-11 250
ModulA 50-11 220
Example of a typical mains connection, 1x230V ±10%, 50 / 60Hz
L
N
Protection
1
(minimum 10A, inert)
FI
Nominal current [A]
0.10 – 0.39
0.10 – 0.64
0.10 – 0.91
0.10 – 1.24
0.10 – 1.47
0.10 – 0.5
0.10 – 0.79
0.10 – 1.03
0.10 – 1.35
0.10 – 1.45
0.10 – 0.50
0.10 – 0.79
0.10 – 1.03
0.10 – 1.35
0.10 – 1.45
0.10 – 0.79
0.13 – 0.68
0.13 – 1.34
0.11 – 1.52
0.11 – 1.45
2
external switch
961807_01
Output P [W]
1
11 – 52
12 – 86
11 – 120
11 – 158
11 – 188
11 – 70
11 – 105
11 – 139
11 – 175
11 – 187
11 – 70
11 – 105
11 – 139
11 – 175
11 – 187
11 – 105
15 – 91
16 – 171
13 – 189
13 – 187
