Baker's Rack
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

B.
C.
Side Frame
Side Frame
1 Pc.
1 Pc.
D.
E.
Side Frame
Side Frame
1 Pc.
1 Pc.

Hardware List

Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
A.
Top
1 Pc.
F.
Back Stretcher
1 Pc.
G.
Shelf
1 Pc.
H.
Adjustable Shelf
1 Pc.
I.
Shelf
2 Pcs.
Nut Cap
1 Pc. (+1 extra)
M6x18
Head Cap Bolt
for Back Stretcher
1 Pc. (+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
K.
Back Stretcher
2 Pcs.
M6x28
Tapered Head Cap Bolt
for Side Bar
4 Pcs. (+1 extra)
M6x16
Tapered Head Cap Bolt
18 Pcs. (+1 extra)
Tools recommended for assembly : Level
J.
Glass Holder
1 Pc.
L.
Stretcher
2 Pcs.
M.
Side Bar
2 Pcs.
M4x12
Wood Screw
for Glass Holder
6 Pcs. (+1 extra)
Adjustable Pin
4 Pcs. (+1 extra)
M4x28
Wood Screw
for Shelf
16 Pcs. (+1 extra)
