88 5081 101
Entertainment Credenza
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
A.
Top
1 pc.
Adjustable Pin
8 pcs.(+1 extra)
For assembly see instructions in carton 88 5
Tools required for assembly : Phillips screwdriver, Drill, 3/8" Drill Bit, Level
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
H.
Back Panel
1 pc.
J.
Back Strip
1 pc.
I.
Back Panel
1 pc.
M3x16
Wood Screw
Magnet
for Magnet
2 pcs.
4 pcs.(+1 extra)
M3x16
Bolt
Wood Screw
for Back Panel
for Hinge
2 pcs.(+1 extra)
12 pcs.(+1 extra)
E.
Base
1 pc.
F.
Front Rail
1 pc.
G.
Back Stretcher
1 pc.
M.
Shelf
2 pcs.
M4x12
Pull Handle
Machine Screw
2 pcs.
2 pcs.
081
102
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Home Styles 88 5081 101
Summary of Contents for Home Styles 88 5081 101
- Page 1 4 pcs.(+1 extra) 2 pcs.(+1 extra) 2 pcs. 2 pcs. 12 pcs.(+1 extra) For assembly see instructions in carton 88 5 Tools required for assembly : Phillips screwdriver, Drill, 3/8” Drill Bit, Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 2 1 pc. 1 pc Door Door 1 pc. 1 pc. Also need the Parts and Hardware in carton 88 5 Tools required for assembly : Phillips screwdriver, Drill, 3/8” Drill Bit, Level Home Styles Consumer Assistance: www.homestyles-furniture.com, servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319...
- Page 3 Assembly Instructions 2/5 IMPORTANT * Do not tighten up all the screws until each part is properly assembled. * After assembly , item must be level to work properly. Use the included adjustable levelers to level. * Use a soft cloth between these parts and the floor. STEP 1 Attach Side Panel (C) and Middle Panel (D) to Base (E), then flip the Locks.
- Page 4 Assembly Instructions 3/5 STEP 3 Attach Front Rail (F) and Back Stretcher (G) to unit, then flip the Locks. Attach Side Panel (B) to unit, then flip the locks. STEP 4 Bolt for Back Panel Slide Back Panel (I), Back Strip (J) and Back Panel (H) into position.
- Page 5 Assembly Instructions 4/5 Figure 5 Figure 6 Figure 7 Figure 8 STEP 5 Attach Top (A) to the unit, then flip the Locks. Insert Adjustable Pins into side panels and middle panel at the desired level. (See Figure 5) Place Shelves (M) into position. Attach Doors (K) and (L) to unit with Wood Screws for Hinges.
- Page 6 Assembly Instructions 5/5 Attention! Attention! To help reduce the risk of the unit tipping over, the Tipover Restraint To help reduce the risk of the unit tipping over, the Tipover Restraint must must be installed following be installed following these instructions exactly! these instructions exactly! Anchor in wall Anchor in wall...
