Automatic Nozzle Height Detection

You may initiate the Automatic Nozzle Height Detection
without the Autoleveling.
In the Calibration section, click " Detect Nozzle".
If consistent warping still occurs after auto-leveling, it may be due to a severe unleveling of
the platform which exceeds the capability of the auto-leveling function. In which case, you
should perform a manual leveling before auto-leveling (see the next page).
You may also level the platform without using the auto-leveling and nozzle detection
functions. Please refer to Page 40 for details.
During nozzle height
detection, the print head
nozzle will touch the thin
metal sheet on the detector
to make measurement.
After nozzle height detection,
the software will ask which type
of print board is used on the
machine, choose the currently
used type of board to finish the
measurement.
12
