General Information

Glossary of Terms

The 30 Degree Boot (left) is the standard boot used in single
bin applications.
The Straight-Out Boot (right) may be used in multiple bin
applications, elevated bins, and systems with less free flowing
feed stuffs.
The Control Unit
(right) is located at
the end of the fill
system. A Power
Unit (left) is secured
to the Control Unit
to turn the auger.
An Extension Boot (optional) may be used to provide addi-
tional length to a system. Multiple Extension Boots may be
used on very long systems.
The fill system may
be controlled by the
Drop Tube Switch
(left) or the Proxim-
ity Level Switch
(right). Both
switches are optional
and must be ordered
separately.
The 30 Degree Two
Motor Tandem Boot
(optional) is used when a
cross auger is required
under two feed bins. This
allows the feed bins to be
set at a 90 degree angle to
the FLEX-AUGER feeder
line.
8
The Lower Boot Com-
ponents, located under
the feed bin, include a
bearing and feed
restrictor.
An Outlet Drop is located at each outlet
opening along the FLEX-AUGER auger line.
very long systems.
The Hopper Level
Control is used to
control the feed level
in the hoppers.
FLEX-AUGER® Feed Delivery System
The Auger Timer (optional)
is used to control the length
of auger run-time. It may be
used as a safety backup to
prevent excessive run time.
MA1032F
