FLEX-AUGER® Feed Delivery System

Three Phase Direct Drive Control Unit (Part No. 25770-6)

KEY DESCRIPTION
1 #10-32 Hex Nut
2** 5/16-18 x 7/8" Socket Hd Cap Screw
3 Switch Box Cover
4 Gasket
5 #6-32 Hex Nut
6 #6 x 3/8" Hex Hd SMS
7 Switch Bracket
8 Switch Insulation
9 Snap Switch
10 #6-32 x 7/8" Pan Hd. Screw
11 1/8 x 1" Rd Hd Rivet
12 Switch Box (Machined)
13 #10-32 Lock Nut
14 Spring
15 #10 Flat Washer
16 Mounting Plate Assembly
17 Seal
18 Body Assembly
19** Anchor Clamp
MA1032F
PART NO.
KEY
4297
20
6850-1
21
6776
22
6777
23
771
24
6782
25
7068
26
1907-5
27
46091
28
1921
29
8757
30
7841
31
6963
32**
6972
33
6723
34**
7908
4873
**These components may be ordered under Chore-Time Part
8276
No. 30313 Driver Assembly.
7703
DESCRIPTION
Paddle
5/16-18 x 1/2" Fastener
5/16" Flat Washer
Tube Anchor Weldment
Slide
5/16-18 Locknut
Diaphragm Assembly
Drop
#10-24 x 5/8" Hx Wash Hd Screw
#8 x 1/2" SMS
Tube Insert
Clamp Kit
Driver Weldment
Terminal Strip
5/16-18 x 2-3/4 Socket Hd Cap Screw
Parts Listing
PART NO.
7896
1839
546
34543
5073
2148
7900
13803
1876
6725
34337
14373
30312
34925-2
6850-2
