Model 108 Bin Placement Chart (With In-Line Or Rotated Screeners) - Chore-Time FLEX-AUGER 108 Installation Instruction

FLEX-AUGER® Feed Delivery System

Model 108 Bin Placement Chart (with In-Line or Rotated Screeners)

Chart for minimum distances ("X") from building to center of bin using the various entrance heights ("H"), upper boots and
System Model Entrance Height
"H"
5' (1.5 m)
Model 108 using
6' (1.8 m)
screener.
7' (2.1 m)
8' (2.4 m)
Screener Boot is in-
9' (2.7 m)
line with system.
10' (3 m)
11' (3.4 m)
12' (3.7 m)
13' (4 m)
14' (4.3 m)
15' (4.6 m)
16' (4.9 m)
17' (5.2 m)
18' (5.5 m)
19' (5.8 m)
20' (6.1 m)
5' (1.5 m)
6' (1.8 m)
Model 108 using
7' (2.1 m)
screener.
8' (2.4 m)
Screener Boot is
9' (2.7 m)
rotated 90 degrees
10' (3 m)
to system.
11' (3.4 m)
12' (3.7 m)
13' (4 m)
14' (4.3 m)
15' (4.6 m)
16' (4.9 m)
17' (5.2 m)
18' (5.5 m)
19' (5.8 m)
20' (6.1 m)
Use this diagram and chart to determine proper
feed bin placement when using screener.
"X" = distance from center of bin to where fill system
enters the building.
"H" = height from top of bin pad to where fill system
enters the building.
Degree of elevation = Angle at which the system is
installed (from horizontal).
System shown with screener boot installed in-line; sys-
tem may also be installed with the screener boot
rotated 90 degrees.
MA1032F
elevations listed below.
30 Degree Upper Bin Boot (part no. 4347)
30 Degree 45 Degree
12.5' (3.8 m) 11.5' (3.5 m)
14' (4.3 m) 12.5' (3.8 m)
16' (4.9 m) 13.5' (4.1 m)
17.5' (5.3 m) 14.5' (4.4 m)
19.5' (5.9 m) 15.5' (4.7 m)
21' (6.4 m) 16.5' (5 m)
23' (7 m) 17.5' (5.3 m)
24.5' (7.5 m) 18.5' (5.6 m)
26.5' (8.1 m) 19.5' (5.9 m)
28' (8.5 m) 20.5' (6.2 m)
29.5' (9 m) 21.5' (6.5 m)
31.5' (9.6 m) 22.5' (6.8 m)
33' (10 m) 23.5' (7.2 m)
35' (10.7 m) 24.5' (7.5 m)
36.5' (11.1 m) 25.5' (7.8 m)
38.5' (11.7 m) 26.5' (8.1 m)
11' (3.4 m) 9.5' (2.9 m)
13' (4 m) 10.5' (3.2 m)
14.5' (4.4 m) 11.5 (3.5 m)
16' (4.9 m) 12.5' (3.8 m)
18' (5.5 m) 13.5' (4.1 m)
19.5' (5.9 m) 14.5' (4.4 m)
21.5' (6.5 m) 15.5' (4.7 m)
23' (7 m) 16.5' (5 m)
25' (7.6 m) 17.5' (5.3 m)
26.5' (8.1 m) 18.5' (5.6 m)
28.5' (8.7 m) 19.5' (5.9 m)
30' (9.1 m) 20.5' (6.2 m)
32' (9.8 m) 21.5' (6.5 m)
33.5' (10.2 m) 22.5' (6.8 m)
35.5' (10.8 m) 23.5' (7.1 m)
37' (11.3 m) 24.5' (7.4 m)
Straight-Out Upper Bin Boot (part no. 6093)
30 Degree 45 Degree
15' (4.6 m) 14' (4.3 m)
16.5' (5 m) 15' (4.6 m)
18.5' (5.6 m) 16' (4.9 m)
20' (6.1 m) 17' (5.2 m)
22' (6.7 m) 18' (5.5 m)
23.5' (7.2 m) 19' (5.8 m)
25.5' (7.8 m) 20' (6.1 m)
27' (8.2 m) 21' (6.4 m)
29' (8.8 m) 22' (6.7 m)
30.5' (9.3 m) 23' (7 m)
32.5' (9.9 m) 24' (7.3 m)
34' (10.4 m) 25' (7.6 m)
35.5' (10.8 m) 26' (7.9 m)
37.5' (11.4 m) 27' (8.2 m)
39' (11.9 m) 28' (8.5 m)
41' (12.5 m) 29' (8.8 m)
11' (3.4 m) 9.5' (2.9 m)
13' (4 m) 10.5' (3.2 m)
14.5' (4.4 m) 11.5' (3.5 m)
16' (4.9 m) 12.5' (3.8 m
18' (5.5 m) 13.5' (4.1 m)
19.5' (5.9 m) 14.5' (4.4 m)
21.5' (6.5 m) 15.5' (4.7 m)
23' (7 m) 16.5' (5 m)
25' (7.6 m) 17.5' (5.3 m)
26.5' (8.1 m) 18.5' (5.6 m)
28.5' (8.7 m) 19.5' (5.9 m)
30' (9.1 m) 20.5' (6.2 m)
32' (9.8 m) 21.5' (6.5 m)
33.5' (10.2 m) 22.5' (6.8 m)
35.5' (10.8 m) 23.5' (7.2 m)
37' (11.3 m) 24.5' (7.5 m)
Planning
15
