Parts Listing

Single Phase Direct Drive Control Unit (Part No. 6500-22)

KEY DESCRIPTION
1* 10-32 Hex Nut
2* 8-32 Hex Nut
3* Switch Box Cover
4* Gasket
5* 6-32 Hex Nut
6* 6x3/8 Washer Hd Screw
7* Switch Bracket
8* Switch Insulation
9* Snap Switch
10* 6-32 x 7/8 Rd Hd Mach. Screw
11* Pin
12* Switch Box
13* 10-32 Hex Lock Nut
14* Spring
15 Washer
16* Mounting Plate Assembly
17 Seal
18 Body Weldment
19* 8-32 x 2-5/8 Hx Hd Mach. Screw
20* Paddle
21 5/16-18 x 1/2 Hx Hd Mach. Screw
22 Flat Washer
23* Pilot Light
24* Terminal Box
25* Toggle Switch
26* Toggle Switch Boot
27* 10-32 Stud
28* Cup Washer
38
PART NO. KEY
4297 29*
6519 30**
6776 31
6777 32
771 33
6782 34
7068 35
1907-5 36
46091 37
1921 38
8757 39**
7909 40**
6963 41
6972 42*
6723 43
7908 44**
4873 - -
8276
7230-1 *May be ordered as an assembly under Chore-Time Part No. 878
7896 Switch Assembly.
1839
546 **May be ordered as an assembly under Chore-Time Part No. 3031
7044 Driver Assembly.
7774
7767
13406
7007
5775
FLEX-AUGER® Feed Delivery System
DESCRIPTION
#10 Star Washer
5/16-18 x 7/8 Socket Hd Cap Screw
8 x 1/2 Sheet Metal Screw
10-24 x 5/8 Slot Hx Hd Mach Screw
Drop
Diaphragm Assembly
5/16-18 Hex Lock Nut
Slide
Tube Anchor
Tube Clamp Kit
Anchor Clamp
Driver Weldment
3/8" Flex Cable
Shoulder Nut
Tube Insert
5/16-18 x 2-3/4 Socket Hd Cap Screw
Liquid Tight Connector
PART NO.
305
6850-1
6725
1876
13803
7900
2148
5073
34543
14373
7703
30312
26982-10
13407
34337
6850-2
23810
MA1032F
