Chore-Time FLEX-AUGER 108 Installation Instruction page 40
Feed delivery system
Hide thumbs
Also See for FLEX-AUGER 108:
- Installation manual (60 pages) ,
- Installation and operator's manual (46 pages) ,
- Installation instruction (14 pages)
Table of Contents
Advertisement
Key
Description
1
5/16-18 x 7/8 Socket Hd Screw
2
Driver Weldment
3
Eyebolt
4
Flange Bearing
5
Front Plate Housing
6
Ball Bearing
7
Adjustment Bracket
8
14" (356 mm) Dia. Sheave
9
5/8" Set Collar
10 2.7" (69 mm) Dia. Sheave
11 Motor Mount Weldment
Key Description
Part No.
6850-1
12 "V" Gripnotch Belt
34346
13 5/16-18 Hex Locknut
1503-2
14 5/16-18 Jam Nut
2196
15 5/16 Flat Washer
2047
16 5/16-18x1-3/4" Hex Hd. M.S.
5930
17 5/16-18 Hex Lock Nut
46301
18 3/16" Key
1500
19 Anchor Clamp
1386
20 5/16-18 Hex Nut
1381
3058
The Belt Drive Parts Package (includes all of the above) may
be ordered under Chore-Time part no. 47870-XX.
Part No.
3096
2148
593
546
4412-4
2148
2112-1
7703
2145
