Removing The Display Panel; Prerequisites; Procedure - Dell Inspiron 24 5000 Service Manual

Identifier
Status
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your
your computer. For more safety best practices, see the Regulatory Compliance home page at
regulatory_compliance.
Identifier
Status

Prerequisites

1 Remove the stand.
2 Remove the back cover.
3 Remove the system-board
4 Remove the base panel.
5 Remove the rear-I/O bracket.
6 Remove the hard drive.
7 Remove the wireless card.
8 Remove the fan.
9 Remove the heat sink.
10 Remove the system board.
11 Remove the camera.
Identifier
Status

Procedure

1 Remove the display-backlit cable from the routing guides on the display-assembly base.
2 Remove the 11 screws (M3x5) that secure the middle frame and display-assembly base to the display panel.
NOTE: The screws that secure the middle frame and display-assembly base to the display panel are silver in color and
etched with "LCD" around the screw holes.
GUID-7D2CEA1B-1FC0-4606-86EB-F51C5DFB6E52
Released
computer. After working inside your computer, follow the instructions in
GUID-AA009E64-E8F7-4B71-924D-104D9EC8D7B5
Released
shield.
GUID-FDC5F9A0-5DFB-4DEC-99BF-2565A42571A8
Released

Removing the display panel

48
After working inside
www.dell.com/
Removing the display panel 95
