- Page 1 Inspiron 24 5000 Setup and Specifications Computer Model: Inspiron 24-5459 Regulatory Model: W12C Regulatory Type: W12C004...
- Page 2 WARNING: A WARNING indicates a potential for property damage, personal injury, or death. Copyright © 2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
-
Page 3: Table Of Contents
Contents Set up your computer............ 5 Views................11 ......................11 Front ......................12 Right ......................13 Left ......................14 Back ......................15 Tilt Specifications............... 17 .................. 17 System information ................17 Dimensions and weight ....................18 Memory ................18 Ports and connectors ..................19 Communications ......................19 Audio... - Page 4 Getting help and contacting Dell........24 ..................24 Self-help resources ..................25 Contacting Dell...
-
Page 5: Set Up Your Computer
Set up your computer Set up the stand. – Pedestal Stand – Articulating stand... - Page 6 Set up the keyboard and mouse. See the documentation that shipped with the keyboard and mouse.
- Page 7 Connect the power adapter. – Pedestal Stand – Articulating Stand...
- Page 8 Press the power button.
- Page 9 Follow the instructions on the screen to finish Windows setup. a) Connect to a network. b) Sign-in to your Microsoft account or create a local account.
- Page 10 Explore Dell resources on your desktop. Table 1. Locate Dell apps Register your computer Dell Help & Support SupportAssist — Check and update your computer...
-
Page 11: Views
Views Front Left microphone (touchscreen) Provides digital sound input for audio recording and voice calls. Left microphone (non-touchscreen) Provides digital sound input for audio recording and voice calls. Camera Enables you to video chat, capture photos, and record videos. Camera-status light Turns on when the camera is in use. -
Page 12: Right
Right microphone (touchscreen) Provides digital sound input for audio recording and voice calls. Right Optical drive Reads from and writes to CDs and DVDs. Brightness control buttons (2) Press to increase or decrease the display brightness. Screen-off button Press and hold to turn off the display; press again to turn on the display. Power button Press to turn on the computer if it is turned off, in sleep state, or in hibernate state. -
Page 13: Left
NOTE: You can customize the power-button behavior in Power Me and My Dell at Options. For more information, see www.dell.com/ support/manuals. Left Media-card reader Reads from and writes to media cards. USB 3.0 ports (2) Connect peripherals such as storage devices and printers. Provides data transfer speeds up to 5 Gbps. -
Page 14: Back
Back Audio-out port Connect audio-output devices such as speakers, amplifiers, and so on. HDMI-out port Connect a TV or another HDMI-in enabled device. Provides video and audio output. HDMI-in port Connect a gaming console, Blu-ray player, or other HDMI-out enabled devices. USB 2.0 ports (4) Connect peripherals such as storage devices and printers. -
Page 15: Tilt
Connect a power adapter to provide power to your computer. Service Tag label The Service Tag is a unique alphanumeric identifier that enables Dell service technicians to identify the hardware components in your computer and access warranty information. Tilt Pedestal stand... -
Page 17: Specifications
Specifications System information Table 2. System information Inspiron 24-5459 Computer model Processor • generation Intel Core i3/i5/i7 series • generation Intel Pentium System chipset H110 Dimensions and weight Table 3. Dimensions and weight Touchscreen Non-touchscreen 385.33 mm (15.17 in) Height 576.62 mm (22.70 in) Width 38.20 mm (1.50 in) -
Page 18: Memory
Memory Table 4. Memory specifications Two SODIMM slots Slots Dual-channel DDR3L Type Speed Up to 1600 MHz Configurations supported 4 GB, 8 GB, 12 GB, and 16 GB Ports and connectors Table 5. Ports and connectors specifications External: Network One RJ45 port •... -
Page 19: Communications
Communications Table 7. Communication specifications Ethernet 10/100/1000 Mbps Ethernet controller integrated on system board Wireless • Wi-Fi 802.11ac • Wi-Fi 802.11b/g/n • Bluetooth 4.0 Audio Table 8. Audio specifications Controller Realtek ALC3661 with Waves Maxx Audio Pro Speakers Speaker Output •... -
Page 20: Media-Card Reader
Media-card reader Table 10. Media-card reader specifications Type One 4-in-1 slot Cards supported • SD card • MultiMediaCard (MMC) • SD Extended Capacity (SDXC) card • SD High Capacity (SDHC) card Camera Table 11. Camera specifications Resolution • Still image: 2.0 megapixels •... -
Page 21: Display
• 130 W Temperature range: Operating 0°C to 40°C (32°F to 104°F) Storage –40°C to 70°C (–40°F to 158°F) Input Voltage 100 VAC to 240 VAC Input frequency 50 Hz to 60 Hz Input current (maximum) 2.50 A 4.62 A/6.70 A Output current (continuous) Rated output voltage 19.50 VDC... -
Page 22: Video
Video Table 15. Video specifications Controller: Intel HD Graphics 530 Integrated Nvidia GeForce 930M Discrete Memory: Integrated Shared system memory Discrete 4 GB GDDR3 Stand Table 16. Stand Pedestal Articulating 215.20 mm (8.47 in) Height 205.28 mm (8.08 in) 225.42 mm (8.87 in) Width 250 mm (9.84 in) 205.60 mm (8.09 in) - Page 23 Operating Storage Altitude (maximum) –15.2 m to 3048 m –15.2 m to 10,668 m (–50 ft to 10,000 ft) (–50 ft to 35,000 ft) * Measured using a random vibration spectrum that simulates user environment. † Measured using a 2 ms half-sine pulse when the hard drive is in use. ‡...
- Page 24 Getting help and contacting Dell Self-help resources You can get information and help on Dell products and services using these self-help resources: Table 18. Self-help resources Information about Dell products and www.dell.com services Dell Help & Support app Get started app...
- Page 25 Enter the Service Tag number or Product ID into the search bar. Contacting Dell To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell. NOTE: Availability varies by country and product, and some services may not be available in your country.
