Replacing The Power-Adapter Port; Procedure; Post-Requisites - Dell Inspiron 24 5000 Service Manual

Identifier
Status
WARNING: Before working inside your computer, read the safety information that shipped with your computer and follow the
steps in Before working inside your
your computer. For more safety best practices, see the Regulatory Compliance home page at
regulatory_compliance.
Identifier
Status

Procedure

1 Align the screw hole on the power-adapter port with the screw hole on the display-assembly base and place the power-adapter port
on the display-assembly base.
2 Replace the two screws (M3x5) that secures the power-adapter port to the display-assembly base.
3 Route the power-adapter cable through the routing guides on the display-assembly base.
Identifier
Status

Post-requisites

1 Replace the system board.
2 Replace the heat sink.
3 Replace the fan.
GUID-A99140DB-7AF3-4218-B305-532FF94DF51D
Released

Replacing the power-adapter port

computer. After working inside your computer, follow the instructions in
GUID-B4E7521C-2804-44F6-9E70-CBB0B5EC2DF3
Released
GUID-1C4E8589-1BC0-42FF-9736-2996E6EFCD94
Released
After working inside
www.dell.com/
Replacing the power-adapter port
