Help Commands
VW [idx] STATUS : Print Video Wall Status
idx=[01...09]: Select Video Wall Index
cidx=[01...09]: Select Config Index
gidx=[A...J]: Select Group Index
cc=[01...09]: Number Of Columns In Video Wall
rr=[01...09]: Number Of Rows In Video Wall
hh=[01...09]: Horizontal Position In Video Wall
vv=[01...09]: Vertical Position In Video Wall
ooo=000: Remove Receiver From hhvv Position
ooo=[001...n]: Select One Output Port
iii=[001...n]: Select One Input Port
name: Max 16 Characters
aa=[100...1000]: Screen Outer Width/Height
ww=[100...1000]: Screen View Width/Height
============= Project Control Commands
SCAN : Scan Network For All Input And Output Devices
SCAN STATUS : Print Scan Results
SCAN RESET : Reset Scan Results
SCAN OSD ON/OFF : Show Scan Index On All Receiver Displays
ASSIGN RESET : Reset All Input/Output/Videowall/Scan Configurations
ASSIGN DF IN iii : Assign Device At Default IP To Input iii
ASSIGN DF IN iii REPLACE : Assign Device At Default IP To Replace Input iii
ASSIGN INDEX ddd IN iii : Assign New Device At Index ddd To Input iii
ASSIGN INDEX ddd IN iii REPLACE : Assign New Device At Index ddd To Replace Input iii
ASSIGN DF OUT ooo : Assign Device At Default IP To Output ooo
ASSIGN DF OUT ooo REPLACE : Assign Device At Default IP To Replace Output ooo
ASSIGN INDEX ddd OUT ooo : Assign New Device At Index ddd To Output ooo
ASSIGN INDEX ddd OUT ooo REPLACE : Assign New Device At Index ddd To Replace Output ooo
ASSIGN AUTO : Auto Assign All New Scanned Devices To Current Project
ddd=[01...n]: Scan List Index value
iii=[001...n]: Select One Input Port
ooo=[001...n]: Select One Output Port
============= General Purpose Input/Output Port Commands
GPIO gg DIR IN/OUT : Set IO Port gg As Input Or Output Port
GPIO gg SET 0/1 : Set IO Output gg To Low(0)/High(1) Level
GPIO gg GET : Get IO Port gg Real Input Level
GPIO [gg] STATUS : Print IO Port gg Status
gg=00: Select All IO Ports
gg=[01...04]: Select One IO Port
============= Network Control Commands
NET LAN2 DHCP ON/OFF : Set LAN2 (Control LAN) DHCP To On Or Off
NET aaaa IP xxx.xxx.xxx.xxx : Set IP Address To xxx.xxx.xxx.xxx
NET aaaa GW xxx.xxx.xxx.xxx : Set Gateway Address To xxx.xxx.xxx.xxx
NET aaaa SM xxx.xxx.xxx.xxx : Set Subnet Mask Address To xxx.xxx.xxx.xxx
aaaa=LAN1: Set Video LAN(POE) Config
aaaa=LAN2: Set Control LAN(Web GUI) Config
NET RB : Reboot Network And Apply New Config
Call This Command After LAN Config Is Changed To Reboot Network
NET TN xxxx : Set Telnet Port To xxxx
