Help Commands
OUT ooo RESET : Reset Output ooo To Factory Default Setting
ooo=000: Select All Output Ports
ooo=[001...n]: Select One Output Port
id=[001...767]: ID value
yyy=[001...n]: Select One Input Port
yyy=AUTO: V/A/R/S/U/C/P follow "OUT ooo FR yyy" command
rr=[0:Bypass 1:2160p@30 2:2160p@24 3:1080p@50 4:1080p@60]
[5:1080i@50 6:1080i@60 7:720p@60 8:720p@50 9:1280x1024@60]
[10:1024x768@60 11:1360x768@60 12:1440x900@60]
[13:1680x1050@60]
tt=[0:Bypass 1:90 2:180 3:270]
ee=[0:Always On 1...9:10~90Seconds]
br=[0:300 1:600 2:1200 3:2400 4:4800 5:9600]
[6:19200 7:38400 8:57600 9:115200]
bit=Data Bits + Parity + Stop Bits, example: 8n1
Data Bits=[5...8], Parity=[n o e], Stop Bits=[1..2]
name: Max 16 Characters
IN iii ID id : Set Input iii To ID id, If New ID Exists Than Swap Them,
Note: DEVICE MUST BE ONLINE
IN iii DEL : Delete Input iii From Current Project Config
IN iii RB : Reboot Input iii And Apply New Config
IN iii RESET : Reset Input iii To Factory Default Setting
IN iii AUD AUTO : Set Input iii Audio To Auto
IN iii AUD HDMI : Set Input iii Audio To HDMI
IN iii AUD ANA : Set Input iii Audio To Embedded Analogue L/R
IN iii NAME name : Set Input iii Device Name To name
IN iii CEC ON/OFF : Set Input iii CEC On Or Off
IN iii FLS ON [time] : Set Input iii Flash Power LED time Seconds
IN iii FLS OFF : Set Input iii Disable Flash Power LED
IN iii LED ee : Set Input iii Front Panel LED Auto Off After ee*10 Seconds
IN iii SG [ON/OFF] [BR br] [BIT bit]: Set Input iii Serial Guest Mode Config
IN iii GUEST: Start Serial Guest Mode To Input iii
Note: To Close Guest Mode Use Command CLOSEACMGUEST
IN [iii] STATUS : Show Input iii Detailed Status
iii=000: Select All Input Ports
iii=[001...n]: Select One Input Port
id=[001...254]: ID value
name: Max 16 Characters
EDID iii CP ooo : Set Input iii EDID Copy From Output ooo
