Help Commands
EDID iii DF zz : Set Input iii EDID To zz
zz=00: HDMI 1080p@60Hz, Audio 2CH PCM
zz=01: HDMI 1080p@60Hz, Audio 5.1CH DTS/DOLBY
zz=02: HDMI 1080p@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=03: HDMI 1080i@60Hz, Audio 2CH PCM
zz=04: HDMI 1080i@60Hz, Audio 5.1CH DTS/DOLBY
zz=05: HDMI 1080i@60Hz, Audio 7.1CH DTS/DOLBY/HD
zz=06: HDMI 1080p@60Hz/3D, Audio 2CH PCM
zz=07: HDMI 1080p@60Hz/3D, Audio 5.1CH DTS/DOLBY
zz=08: HDMI 1080p@60Hz/3D, Audio 7.1CH DTS/DOLBY/HD
zz=09: HDMI 4K@30Hz 4:4:4, Audio 2CH PCM
zz=10: HDMI 4K@30Hz 4:4:4, Audio 5.1CH DTS/DOLBY
zz=11: HDMI 4K@30Hz 4:4:4, Audio 7.1CH DTS/DOLBY/HD
zz=12: DVI 1280x1024@60Hz, Audio None
zz=13: DVI 1920x1080@60Hz, Audio None
zz=14: DVI 1920x1200@60Hz, Audio None
zz=15: HDMI 4K@30Hz 4:4:4, Audio 7.1CH(Default)
zz=16: HDMI 4K@60Hz 4:2:0, Audio 2CH PCM
zz=17: HDMI 4K@60Hz 4:2:0, Audio 5.1CH DTS/DOLBY
zz=18: HDMI 4K@60Hz 4:2:0, Audio 7.1CH DTS/DOLBY/HD
CLOSEACMGUEST : Close Input Or Output Guest Mode
============= Video Wall Control Commands
VW idx CREATE ccXrr [name] : Create Video Wall idx Of size Column cc X Row rr
VW idx NAME name : Set Video Wall idx Name To name
VW idx DEL: Delete Video Wall idx
VW idx OUT ooo HhhVvv : Video Wall idx Assign Receiver ooo To Position Horizontal hh
And Vertical vv
VW idx C cidx CREATE [name] : Create Video Wall idx Config cidx
VW idx C cidx NAME name : Set Video Wall idx Config cidx Name To name
VW idx C cidx APPLY : Apply Video Wall idx Config cidx
VW idx C cidx DEL : Delete Video Wall idx Config cidx
VW idx C cidx G gidx HhhVvv : Set Video Wall idx Config cidx Position hh,vv To Group gidx
VW idx C cidx G gidx FR iii : Set Video Wall idx Config cidx Group gidx From Input iii
VW idx C cidx S HhhVvv : Set Video Wall idx Config cidx Position hh,vv To Single Mode
VW idx C cidx S HhhVvv FR iii : Set Video Wall idx Config cidx Group gidx From Input iii
VW idx HhhVvv OWaa VWww : Set Video Wall idx Position hh,vv Outer Width aa And View Width ww
VW idx HhhVvv OHaa VHww : Set Video Wall idx Position hh,vv Outer Height aa And View Height ww
aa=[100...1000]: Screen Outer Width/Height
ww=[100...1000]: Screen View Width/Height
