Status feedback samples
Command: STATUS
================================================================
IP Control Box ACM200 Status Info
FW Version: 1.14
Power IR Baud
On On 57600
In EDID IP
001 DF009 169.254.003.001 On /On
002 DF016 169.254.003.002 On /On
Out FromIn IP
001 001 169.254.006.001 On /Off 00 VW02
002 002 169.254.006.002 On /Off 00 VW02
LAN DHCP IP
01_POE Off 169.254.002.225 169.254.002.001 255.255.000.000
02_CTRL Off 010.000.000.225 010.000.000.001 255.255.000.000
Telnet LAN01 MAC
0023 34:D0:B8:20:4E:19
================================================================
Command: OUT 001 STATUS
================================================================
IP Control Box ACM200 Output Info
FW Version: 1.14
Out Net HPD Ver
001 On Off A7.3.0 VW
Fast Fr Vid/Aud/IR_/Ser/USB/CEC
On 001 001/004/000/000/002/000
CEC DBG Stretch IR
On On Off On On
IM MAC
Static 00:19:FA:00:59:3F
IP GW
169.254.006.001 169.254.006.001 255.255.000.000
================================================================
12
NET/Sig
NET/HDMI Res Mode
Gateway SubnetMask
LAN02 MAC
34:D0:B8:20:4E:1A
Mode Res Rotate Name
00 0 Receiver 001
HDR MCas
On
BTN LED SGEn/Br/Bit
3 Off /9/8n1
SM
On
