Terminal Identification - Altronix WPTV244UL Series Installation Manual

WARNING: This installation should be made by qualified service personnel. Unit should be installed in
accordance with the National Electrical Codes and all local codes. For continued protection against risk
of fire replace all fuses only with the same type and rating (15 amp/250V).
PD4 - Power Distribution Module
1P - 3P
1N - 3N
4P
4N

Terminal Identification:

AC output, PTC protected, power limited, Class 2 Rated.
AC output, common.
AC output, fused, non-power limited.
AC output, common.
- 3 - - 3 -
