Simplex 4100ES Installation & Maintenance page 71

Step 4. Wiring Network Cards,
Wiring with the
Wired Media Card
(continued)
Continued
The Table below lists the 4100ES master motherboard connections for the wired media
card.
Table 4-5. 566-227 CPU Motherboard Wired Media Connections
Motherboard Port for Media
Card Connected to P5
TB1-4
TB1-5
TB1-6
TB1-7
TB1-8
Motherboard Port for Media
Card Connected to P6
TB3-1
TB3-2
TB3-3
TB3-4
TB3-5
Figure 4-8, below, shows how two CPU motherboards with wired media network cards
connect to each other in the 4100ES.
R+ R-
18 AWG
TB3
1 10
Right Port
Figure 4-8. Wired Media Interconnections between 4100ES Master
Wired Media Card Connection
(Left Port)
0 V
Earth ground
INV (-)
None
NONINV (+)
Wired Media Card Connection
(Right Port)
NONINV (+)
Reserved
INV (-)
Earth ground
0 V
Motherboards
4-14
Left Port
TB1
8 1
L+ L-
Continued on next page
