- Page 1 UsER MANUAl KETTY 5.0 MADE ITALY design & production 004320026 - Rev 002...
- Page 2 APPLY TECHNICAL DATA LABEL ENGLISH...
-
Page 3: Table Of Contents
MaINtENaNcE ..............................6 INStaLLatIoN ..................................7 Ventilation and aeration of the installation premises ..................... 8 flUe disCharGe ........................................8 KEtty 5.0 dEtaILS ................................10 StovE poSItIoNING ............................... 11 NotE for corrEct opEratIoN ..........................11 bUlb thermostat reaCtiVation ................................11 fUse ............................................11 pELLEtS aNd LoadING .............................. -
Page 4: English
We thank you for having chosen our company; our product is a great heating solution developed from the most advanced technology with top quality machining and modern design, aimed at making you enjoy the fantastic sensation that the heat of a flame gives, in complete safety. Warnings This instructions manual is an integral part of the product: make sure that it always accompanies the appliance, even if transferred to another owner... - Page 5 RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT THEY UNDERSTAND THE INHERENT DANGERS. Š THE GENERATOR MUST NOT BE USED BY PERSONS (INCLUDING CHILDREN) WITH REDUCED PHYSICAL, SENSORY AND MENTAL CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR THEIR SAFETY.
-
Page 6: Routine Maintenance
THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE TECHNICAL AFTER-SALES SERVICE AND ALWAYS DISABLE THE SAFETY SYSTEMS. Š IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE BRIGADE. -
Page 7: Installation
INsTAllATION GENERAl The support surfaces and/or points must have a suitable load-bearing capacity to support the weight of the appliance, of the accessories and coatings. The generator must be on the level for correct operation. The flue extraction and hydraulic connections must be carried out by qualified personnel who must issue documentation of conformity according to the regulations of the country of installation. -
Page 8: Ventilation And Aeration Of The Installation Premises
VENTIlATION ANd AERATION Of ThE INsTAllATION PREMIsEs Ventilation, in the case of a non-watertight generator and/or non-watertight installation, must be carried out respecting the minimum area indicated below (considering the largest of the values suggested: Percentage of the Minimum net opening value of the Appliance categories Reference standard net opening section with respect to the... - Page 9 shAREd ChIMNEY fluE Check on the CE Technical Data Sheet whether the product is suitable for installation in a shared chimney flue (i.e. with multiple connection). Suitable devices can be installed in shared flue systems provided that: Š installation in a shared chimney flue (i.e. with multiple connection) is allowed in the place of installation; Š...
-
Page 10: Ketty 5.0 Details
KETTY 5.0 DETAIls Room air outlet Pellet hopper On/Off fuse Access to combustion chamber 230V power supply Bulb thermostat reactivation and ash drawer Room probe Serial input Rear flue gas outlet Additional thermostat Display Combustion air inlet Input ENGLISH... -
Page 11: Stove Positioning
sTovE posITIonInG To ensure the stove works correctly, it should always be positioned so that it is perfectly level, using a spirit level. noTE For CorrECT opErATIon Pellet hopper lid The following indications must be respected for correct pellet stove operation: Both during stove operation and when it is not used, all hatches (pellet hopper, door, ash drawer) must remain closed at all times. -
Page 12: Pellets And Loading
PELLETS AND LOADING Pellets are made by subjecting wood shavings i.e. the rejects of pure unpainted wood from sawmills, carpentry products and products from other activities connected to wood working and transformation, to very high pressures. This type of fuel is fully ecological as no glues are used for its compaction. In fact, pellet compactness is guaranteed over time by a natural substance found in wood: lignin. -
Page 13: Remote Control (Option)
Remote contRol (oPtIon) The remote control can be used to adjust the main stove functions. Transmitter Select air mode Display Lock keyboard On/off stove (hold for 3 seconds) Degrees Celsius / Fahrenheit Set power Press the button once to enable or disable the chrono Set switch-off delay: The button allows to set the switch-off delay. -
Page 14: Remote Control Icons
Remote contRol Icons Air mode selected: Enable chrono Flashing QUIET Light on = activated REGULAR Light off = deactivated Indicates the transmission of the radio signal Set switch-off delay On = during all radio communication Off = radio communication absent Battery low Keys locked Set power level. -
Page 15: Control Board
Control Board ViewiNg OF VariOus tO aCCess ON/OFF text messages tHe meNu ON/OFF settiNgs OPeratiNg POwer temPerature ICon key indicates the presence of an alarm. indicates the status of the weekly programming Off: indicates that there are no alarms Off: deactivated. On: indicates the presence of an alarm On: activated. -
Page 16: General Menu
General menu go back - exit scroll parameters: next (3); previous (2) Change settings data: increase (4); decrease (5) Confirm - access menu MODE VENTILATION EASY SETUP CHRONO ENABLING CHRONO MODE PRG1 SETTINGS DATE-TIME PRG2 LANGUAGE PRG3 DISPLAY PRG4 STAND-BY DELTA T FIRST LOAD *STOVE STATUS... -
Page 17: First Ignition Settings
FIrst IGnItIon settInGs after connecting the power cord at the back of the generator, turn the switch (if any) to position (i). the switch is used to power the heat generator board. date-tIme this menu allows the date and time to be set. CONtrOLs PrOCeDure Š... -
Page 18: Operation And Logic
oPeratIon and loGIC IGnItIon Once the previously listed points have been checked, press key 1 for three seconds to ignite the stove. During ignition, the stove will check for a flame for a period of 15 minutes. when the right temperature is reached, the stove will switch from ignition to PreParatiON. the stove is set to maNuaL mode, power 5, by default. -
Page 19: Mode
mode this menu is used to set the operating logic of the machine for the power used. range: (maNuaL, temPerature set, aux) By selecting maNuaL mode, the user can choose the heat output level delivered and the type of VeNtiLatiON, according to his/her preferences. -
Page 20: Easy Setup
easy setuP the volumetric weight of the pellet is the ratio between the weight and the volume of the pellet. this ratio may change without altering pellet quality. By using the easY setuP function, it is possible to dose the pellets by increasing or decreasing the preset values. in the stove program, the available values range from “–... -
Page 21: Prg 1-4
PrG 1-4 Prg x allows you to set the ignition and switch-off time, the days of use of the programmed time slot, the temperature and also the desired power. Current day and time settings are essential for the correct operation of the Chrono. CONtrOLs PrOCeDure Š... -
Page 22: Example
eXamPle CHrono tIme slot 02:00 08:00 16:30 23:00 MANUAL 02:00 08:00 16:30 23:00 Power start 02:00 time slot 1 Power 5 stop 23:00 02:00 08:00 16:30 23:00 start 08:00 time slot 2 Power 1 02:00 08:00 16:30 23:00 stop 16:30 22°C stove setting 02:00... -
Page 23: Settings
settInGs • DATE-TIME • LANGUAGE See chapter: firSt ignition SettingS • DEGREES dIsPlay this menu allows you to adjust the brightness of the display. the values range from OFF, 1 to 20. if set to OFF, the display backlighting is set to maximum brightness and turns off after a 60 second delay. -
Page 24: Delta-T
delta-t this function allows the hysteresis thresholds to be set for stove ignition (DeLta-t ON) and switch-off (DeLta-t OFF), used as a room temperature adjustment interval if not managed by an external thermostat. the possible values for DELTA-T go from: 0.5 - 5°C CONtrOLs PrOCeDure Š... -
Page 25: Additional Functions
addItIonal FunCtIons addItIonal tHermostat InstallatIon (oPtIonal) the stove can control the room temperature through an additional thermostat (optional). after ignition (by pressing key 6 or in chrono mode), the stove will work to reach the set value on the thermostat, displaying wOrK (closed contact) on the screen. -
Page 26: Cleaning And Maintenance
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM Cleaning and maintenanCe always follow the instruCtions in Complete safety! Š Make sure that the power cord is unplugged because the generator may have been programmed to switch on. - Page 27 burn pot and Combustion Chamber: Š Vacuum the residue in the burn pot Š Remove the burn pot completely from the relevant compartment; Š Vacuum the ash from the burn pot slot, ignition plug pipe holder and combustion chamber. Š Clear/clean all the holes in the burn pot. Š...
- Page 28 removable ash drawer: Š Remove the ash drawer and empty it in a dedicated container. PARTS FREQUENCY IN DAYS* BURN POT (USER) COMBUSTION CHAMBER (USER) REMOVABLE ASH DRAWER** (USER) T-SHAPED FITTING / SMOkE DUCT (QUALIFIED TECHNICIAN) * Average use 8h at max. nominal power. ** How often the ash drawer is emptied depends on a number of factors: the type of pellets, the stove output, the use of the stove and the type of installation.
-
Page 29: Routine Maintenance Performed By Qualified Technicians
TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM routine maintenanCe performed by Qualified teChniCians routine maintenance must be performed at least once a year. Since the generator uses pellets as solid fuel, it requires annual routine maintenance, which must be performed by a Qualified technician, using only original spare parts. - Page 30 TO FIND OUT WHERE YOUR NEAREST SERVICE CENTRE IS, CONTACT YOUR DEALER OR VISIT THE WEBSITE: WWW.LANORDICA-EXTRAFLAME.COM THE IMAGES ARE FOR ILLUSTRATIVE PURPOSES. Fumes motor (dismantle and clean the smoke duct and "T"), new seal where required Gaskets, pellet hopper, inspections, ash drawer and door (replace and apply silicone where indicated)
-
Page 31: Displays
Displays Display Reason Generator off sTaRT The start-up phase is in progress pelleT loaDinG Continuous pellet loading is in progress during the ignition phase iGniTion The ignition phase is in progress pRepaRaTion The preparation phase is in progress WoRk The normal work phase is in progress MoDulaTion The generator is working at minimum final cleaninG... -
Page 32: Disposal
Disposal InformatIon for management of electrIc and electronIc applIance waste contaInIng batterIes or accumulators This symbol, which is used on the product, batteries, accumulators or on the packaging or documents, means that at the end of its useful life, this product, the batteries and the accumulators included must not be collected, recycled or disposed of together with domestic waste. Improper management of electric or electronic waste or batteries or accumulators can lead to the leakage of hazardous substances contained in the product. -
Page 33: Symbol En 16510-1
Symbol EN 16510-1 EN 16510-1 EXPLANATION Symbol Nominal heat output part Part load heat output CON / INT Appliance operation, Continuos (CON) or Intermittent (INT) / CO Carbon dioxide emission 2 nom 2 part / CO Carbon monoxide emission part Minimum distances to combustible materials - bottom Minimum distances to combustible materials - ceiling Minimum distances to combustible materials - floor in front... - Page 34 ENGLISH...
- Page 35 ENGLISH...
- Page 36 CONTACT YOUR DEALER OR CONSULT THE SITE WWW.LANORDICA-EXTRAFLAME.COM The manufacturer reserves the right to vary the characteristics and the data reported in this pamphlet at any moment and without notice, in order to improve its products. 04/04/2025 004320026-002 MAN.UT. KETTY 5.0 [E281]...
