This cart is compatible with SV41, SV42, SV43, and SV44 drawers.
It is not compatible with SV31 or SV32 drawers.
Components
4x
After unpacking the cart, remove the 4
protective layers from the ends of the cart.
For the latest User Installation Guide please visit: www.ergotron.com
User's Guide - English
Guía del usuario - Español
Manuel de l'utilisateur - Français
Gebruikersgids - Deutsch
Benutzerhandbuch - Nederlands
Guida per l'utente - Italiano
Användarhandbok - svenska
ユーザーガイ ド : 日本語
用户指南 : 汉语
888-24-286-G-00 rev. C • 04/14
StyleView Transfer Cart
1x
User's Guide
Drawers sold separately.
Tools Needed
1 of 8
Advertisement
Table of Contents
Related Manuals for Ergotron StyleView SV41
Summary of Contents for Ergotron StyleView SV41
- Page 1 Tools Needed After unpacking the cart, remove the 4 protective layers from the ends of the cart. For the latest User Installation Guide please visit: www.ergotron.com User's Guide - English Guía del usuario - Español Manuel de l’utilisateur - Français...
- Page 2 To install batteries for electronic lock function. Unlock cart using provided key then lift right handle up to open door. Open right door then left door. Push top cover tabs in and up to release top cover. Lift front edge of top cover up a little then pull rear tabs out of slots to remove top cover. 888-24-286-G-00 rev.
- Page 3 Install the 4 provided D batteries. a. Slide top cover tabs into slots. b. Lower cover so tabs slide into slots. c. Make sure all 4 cover tabs click into place to secure top cover. 888-24-286-G-00 rev. C • 04/14 3 of 8...
- Page 4 Install drawers by sliding onto shelves. NOTE: Drawers sold separately. 888-24-286-G-00 rev. C • 04/14 4 of 8...
- Page 5 Open doors on other side of cart for shelf access. a. Unlock doors with key, then lift up on right handle to open door after unlocked. b. Slide drawers onto shelves. How to adjust height of, or remove, scanner holder. Do not remove screws! Loosen screws just enough to slide holder up or down in the T-slot.
- Page 6 • #4 LED is fl ashing. -Replace batteries (D-cell alkaline only). • Door won’t open when User PIN is entered. -Test system by entering Master PIN. If door doesn’t unlock, contact Ergotron customer care for "Lost Master PIN" instructions. Flashing LED: Meaning 3 &...
- Page 7 How to remove shelves. a. Push in and up on the 2 tabs under the shelf edge at the center of the cart. b. With shelf angled, slide out of cart. NOTE: Shelf tabs are at the center of the cart under each shelf. How to attach shelves.
- Page 8 Changes or modifi cations not expressly approved by Ergotron, Inc. could void the user’s authority to operate the equipment.
