- Page 1 -- OBV-100AK –– BEACH VOLLEYBALL ANCHOR KIT Installation Instructions Call Jaypro Sports Equipment at 1-800-243-0533 during regular business hours for technical support. www.jaypro.com Page 1 of 5...
- Page 2 OBV100AK PARTS LIST (QTY: SINGLE UNIT) IMAGE DESCRIPTION (1) INSERT ANCHOR (P/N: OBV100-C) (2) STAKE FLAG 4'' x 5'' YELLOW (P/N: HM6633) (3) PLASTIC CORD GRIP 1/4''NPT (P/N: HM6634) (4) PLASTIC NUT, 1/4''NPT (P/N: HM6635) (5) 1/2" WASHER FLAT STD, SS (P/N: HW5025) (6) BLACK VINYL CAP (P/N: EC0069)
- Page 3 Anchor Kits: Model OBV-100AK – Insert Anchor An inverted design that elements the potential of sand and water contamination that can make removal difficult. Anchor is completely removable. Provided with a cap and identifying flag to safely identify its location beneath the sand.
- Page 4 WHENEVER THE GROUND INSERT (6) IS NOT IN USE, IT SHOULD REMAIN COVERED WITH THE MARKER FLAG BOTH TO ENSURE THAT THE INSERT ISN'T FILLED WITH SAND AS WELL AS TO INDICATE THE LOCATION OF THE INSERT. PROCEDURE INSERT CORD GRIP (3) INTO TOP CAP (1). INSTALL WASHERS (5) AND NUT (4).
- Page 5 FOOTING DETAIL (OPTIONAL ANCHOR KIT PN/: OBV-100AK) FOR THE MOST VERSATILE FACILITY, ITS RECOMMENDED TO INSTALL POLES 36'-0" FROM EACH OTHER TO ALLOW FOR BOTH COMPETITION AND RECREATIONAL PLAY. Page 5 of 5...
