- Page 1 INSTALLATION AND OPERATION MANUAL ESP SERIES POWER AMPLIFIER ES2120P...
-
Page 2: Important Safety Information
Assurez-vous que l’appareil est hors tension avant de connecter les hauts parleurs. Veri ez que la sortie des enceintes soit protégées contre un contact physique. Respecter les polarités des terminaux ainsi que le câblage des enceintes pendant le fonctionnement afin d’assurer une utilisation sécurisee. ESP SERIES INSTALLATION AND OPERATION MANUAL... - Page 3 The ES2120P is a 2RU 2 channel 120W amplifier. This amplifier features Rear Panel 100V line and 4Ω output. Installation The Australian Monitor ESP series gives the contractor a low cost Troubleshooting solution in applications that are price sensitive but still require Dimensions a high quality of sound reproduction and reliability.
-
Page 4: Protection Features
ES2120P - 2 x 120W • 100V and 4Ω outputs • XLR Through Output • Level Adjustment • 2 RU PROTECTION FEATURES Short-circuit protection • • Over load protection • Thermal protection ES2120P AMPLIFIER BLOCK DIAGRAM ESP SERIES INSTALLATION AND OPERATION MANUAL... -
Page 5: Front Panel
This LED indicates that the amplifier is protection due to a short circuit or overload condition at the output terminals. POWER SWITCH This switches the power to the unit on and off. The up position is on. ESP SERIES INSTALLATION AND OPERATION MANUAL... -
Page 6: Rear Panel
This is a standard IEC 60320-C14 socket. It accepts a standard IEC mains cable, provided. The fuse drawer contains the mains fuse and a spare. Consult the specification section for fuse ratings. Always replace the fuse with one of the same value and type. Always disconnect power to the amplifier before replacing fuses. ESP SERIES INSTALLATION AND OPERATION MANUAL... -
Page 7: Installation
INSTALLATION POWER REQUIREMENTS Power consumption for your model of the ESP Series amplifier is indicated on the rear panel for 1/8th output power. Ensure that your mains voltage is the same as the rear panel mains voltage marker (±10%). MOUNTING The ESP Series amplifiers are two rack units high (2U) and will fit a standard EIA 19”... -
Page 8: Troubleshooting
Reduce volume levels on rear panel No sound but amplifier is on Volume controls down Check volume controls Amplifier has overheated Check for obstructions above and below Make sure the amplifier is well ventilated ESP SERIES INSTALLATION AND OPERATION MANUAL... - Page 9 DIMENSIONS ESP SERIES INSTALLATION AND OPERATION MANUAL...
-
Page 10: Specifications
A-Weighted AUDIO SENSITIVITY AUDIO INPUT SENSITIVITY 150mV 150mV Rated Power, 100V Output NO LOAD VOLT.4Ω 22.5V 4Ω LOADED VOLT 4Ω 22.1V 4Ω LED SIGNAL -34dBr AUDIO MISCELLANEOUS INPUT IMPEDANCE 20kΩ > 57dBr INPUT CMRR ESP SERIES INSTALLATION AND OPERATION MANUAL... - Page 11 0°C to 40°C (95% RH) FINISH Powder Coated Steel COLOUR Black (Satin) ACCESSORIES IEC Mains cable, Rubber Feet x 4 APPROVALS CE, IEC, RCM Due to continuous improvements, all specifications are subject to change ESP SERIES INSTALLATION AND OPERATION MANUAL...
- Page 12 ENGINEERED BY AUSTRALIAN MONITOR Address: Unit 1, 2 Daydream Street, Warriewood NSW 2102 Australia Website: www.australianmonitor.com.au International enquiries email: international@australianmonitor.com.au ABN 86 003 231 187...
