SETTING UP PROCEDURE

To set the width of paper, loosen thumbscrew
1 knob on the side guide and slide to position.
Use scales as reference point.
Fan paper before loading. This will reduce
2 static and toner adhesion due to printing. For
best result, the paper stack should be flat.
Push the feed tray down and load the paper.
3
Readjust paper guide if needed.
Adjust tray pressure. For thinner paper, the
4 number should be higher. For heavier paper the
number should be lower.
Use slitter registration adjustment knob to
5 compensate for printing registration. The knob
will allow ± 2mm of adjustment.
Auxiliary roller is for hard to feed paper. To use
6 auxiliary roller, laid the rollers down onto the
paper.
Page 9
Thumbscrew
knob
Paper feed guide
Scales
