TROUBLESHOOTING

Out of paper
miss feed
jam sensor 2
jam sensor 3
check top cover
check rear cover
Finish card not clean and neat
Error message cannot reset

OPTIONAL SLITTER CASSETTE

Optional slitters enable the CC-330 to have more range of applications. Follow the step below the replace
optional slitter cassette.
1. Lift Top Cover
2. Remove thumbscrew by turning counter-
clockwise on both side of the slitter cassette.
3. Using both hands, lift the slitter cassette.
4. Replace with the desired slitter cassette.
5. Secure the slitter cassette with the
thumbscrew by turning them clockwise.
Error Troubleshooting
Feed tray empty
1. Adjust the feed tray tension
2. Side guide too tight. Adjust side guide.
3. Fan the paper and re load the paper into hopper
1. Remove the paper jam by pulling toward stacking tray.
2. Adjust the feed hopper tension, if double feed
happens
1. Use JOG key to clear the jam
2. Adjust feed hopper tension, if double feed happens
Put the top cover in position
Put the rear cover in position
Call for service
Check covers and paper jam
Page 19
Thumbscrews
Lift Handles
