Originalbetriebsanleitung
3–7
PumPe Lutz B2 Vario
GB
Operating Instructions
9–13
PumP Lutz B2 Vario
Typ/Type
Lutz B2 Vario PP 32-DL
Lutz B2 Vario Niro 28-DL
Vor Inbetriebnahme Betriebsanleitung lesen!
Read this operating instructions before start up!
Für künftige Verwendung aufbewahren.
IP24
To be retained for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the B2 Vario and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Lutz B2 Vario

  • Page 1 3–7 PumPe Lutz B2 Vario Operating Instructions 9–13 PumP Lutz B2 Vario Typ/Type Lutz B2 Vario PP 32-DL Lutz B2 Vario Niro 28-DL Vor Inbetriebnahme Betriebsanleitung lesen! Read this operating instructions before start up! Für künftige Verwendung aufbewahren. IP24 To be retained for future reference.
  • Page 2 Bild / Fig. 1 Bild / Fig. 2 Bild / Fig. 3 Bild / Fig. 4 Bild / Fig. 5 Bild / Fig. 6...
  • Page 3 . Sachwidrige Verwendung ................5 3. Lieferumfang ....................5 4. Inbetriebnahme ....................6 5. Bedienung .......................6 5.1 Ein- und Ausschalten, Drehzahleinstellung ..........6 5. Überlastung der Pumpe ................6 6. Pflege und Wartung ..................6 7. Reparaturen ....................6 Ersatzteil-Liste Pumpe Lutz B Vario ............14-18 Konformitätserklärung ..................19...
  • Page 4 Allgemeine Sicherheitshinweise Folgende Sicherheitshinweise sind zu beachten: Die Betriebsanleitung ist: • als Bestandteil des Produkts zu betrachten. 1. Die Pumpe ist nicht explosionsgeschützt. • vor Inbetriebnahme vom Bediener der Pumpe zu Die Pumpe darf nicht in explosionsgefährdeter Um- lesen und während des Betriebs einzuhalten. gebung verwendet werden.
  • Page 5 1. Bestimmungsgemäße Verwendung 2. Sachwidrige Verwendung Die Pumpe Lutz B Vario ist eine dichtungslose, vertikale Die Pumpe ist nicht zur Verwendung in oder an Tauchkreiselpumpe mit einem axial wirkenden Rotor. Sie Schwimmbecken, Gartenteichen oder ähnlichen Orten dient ausschließlich zum Um- und Abfüllen von reinen, zugelassen.
  • Page 6 6. Pflege und Wartung Befestigen Sie zunächst die Aufhängevorrichtung (Pum- Es ist erforderlich, die Pumpe nach Gebrauch in aggres- penset Lutz B Vario) an einem geschützten und doch siven, klebenden oder stark verschmutzten Flüssigkeiten leicht zugänglichen Platz, damit Ihre Pumpe nach jedem ausreichend zu spülen (siehe Bild 5).
  • Page 7 Tabelle 1 Pumpe Lutz B2 Vario PP 32-DL Lutz B2 Vario Niro 28-DL Tauchtiefe 500 mm 700 mm 1000 mm 500 mm 700 mm 1000 mm Fördermenge max. 75 l/min 68 l/min Förderhöhe max. 7 m WS 6,5 m WS Max.
  • Page 9: Table Of Contents

    3. Scope of supply ....................11 4. Starting up ....................1 5. Operation ......................1 5.1 Starting/interruption, speed control ............1 5. Overload of the pump ................1 6. Maintenance and care ...................1 7. Repairs ......................1 Spare part list Pump Lutz B Vario ............. 14-18 Declaration of Conformity .................19...
  • Page 10: General Safety Information

    General safety information Following safety information must be observed: The operating instruction has to be considered 1. The pump is not explosion proof. • part of the product. The pump is not allowed to be operated in explosion • must be read by the operator of the pump before hazard areas.
  • Page 11: Proper Use

    1. Proper use 2. Improper use The pump Lutz B Vario is a sealless, vertical centrifugal The pump is not approved for use in or on swimming pump with axially acting rotor. The pump is used to pools, garden ponds, etc.
  • Page 12: Starting Up

    4. Starting up 6. Maintenance and care First secure the wall bracket (pump set Lutz B Vario) in The pump must be thoroughly rinsed whenever it has a sheltered, yet easily accessible place so that the pump been used in aggressive, adhesive or highly contaminated can be stored away correctly whenever it is not in use.
  • Page 13 Table 1 Pump Lutz B2 Vario PP 32-SL Lutz B2 Vario SS 28-SL Immersion depth 500 mm 700 mm 1000 mm 500 mm 700 mm 1000 mm Delivery rate max. 75 l/min 68 l/min Delivery head max. 7 m wc 6.5 m wc...
  • Page 14: Spare Part List Pump Lutz B Vario

    Ersatzteil-Liste Spare Part List Pumpe Lutz B2 Vario Pump Lutz B2 Vario Best.-Nr. Order No Bezeichnung Description Qty. 000-015 Griff kpl. für Motor 0-40V, 50Hz grip cpl. for motor 0-40V, 50Hz beinhaltet: 000-061, 000-06, 0344-050 including: 000-061, 000-06, 0344-050 000-016 Griff kpl.
  • Page 15 Ersatzteil-Liste Spare Part List Pumpe Lutz B2 Vario Pump Lutz B2 Vario Best.-Nr. Order No Bezeichnung Description Qty. 031-147 • Rillenkugellager grooved ball bearing 0333-050 • Kohlebürste carbon brush 0336-050 Knickschutztülle rubber cap 0336-077 Knickschutztülle für US-Kabel rubber cap for US-cable 0336-109 Kabeldurchführung...
  • Page 19: Declaration Of Conformity

    EN 60 335-1 EN 55 014- EN 60 335-1 EN 55 014- Angewandte nationale Normen und technische Spezifikationen, ins- Applicable national standards and technical specifications, in parti- besondere cular: DIN 45635 DIN 45635 Wertheim, 01.03.008 Jürgen Lutz, Geschäftsführer, Managing Director...
  • Page 20 Lutz - Pumpen GmbH Erlenstraße 5-7 D-97877 Wertheim Tel. (0 93 4) 8 79-0 Fax (0 93 4) 87 94 04 e-mail: info@lutz-pumpen.de http://www.lutz-pumpen.de Technische Änderungen vorbehalten. 03/08 Subject to technical changes. Best.-Nr. 0698-130 Printed in Germany / Dru.
