- Page 1 Translation of the original instructions MOTOR B1 BATTERY MOTOR B2 BATTERY Please read this manual before starting up. To be retained for future reference.
-
Page 3: Table Of Contents
Table of Contents 1. Concerning this manual ........................4 1.1 Terms ............................4 1.2 Target groups ..........................4 1.3 Associated applicable documents ....................4 1.4 Warnings and symbols ....................... 5 1.5 Latest state ..........................5 1.6 Copyright ..........................5 2. Safety ..............................6 2.1 General safety information ...................... -
Page 4: Concerning This Manual
1. Concerning this manual This manual • is part of this product • is valid for all mentioned series • describes the safe and proper use in all operating stages 1.1 Terms User: Single person or organisation who is using the products e.g. customer, user, assistant Children: Young persons up to and including the age of 14 years. -
Page 5: Warnings And Symbols
Information / Recommendation ► What to do → Cross reference Requirement Tab. 4: Symbols and meaning 1.5 Latest state Please find the latest state of this operating instruction under www.lutz-pumpen.de. 1.6 Copyright The content of this operating instruction and the images contained in them are subject to the copyright protection of Lutz Pumpen GmbH. -
Page 6: Safety
2. Safety The manufacturer will not be held responsible for any damages resulting from non-compliance of the overall documentation, in particular for damages in case of non-compliance of the operating instructions. 2.1 General safety information Observe following regulations before accomplishing all activities. Product safety The motor is constructed in conformity with the state of the art and approved safety-related standards. - Page 7 Personnel qualification • This device must not be used by children. It may be used by persons of reduced physical, sensory or mental capacity or by persons lacking in experience or knowledge provided that they are supervised or have been instructed in the safe use of the device and understand the associated hazards. Cleaning or user maintenance must not be performed by children. •...
-
Page 8: Proper Use
2.2 Proper use A battery powered drum and container pump consists of drive motor B1 Battery or B2 Battery and pump tube to suit the particular application. The pump is only used to transfer pure, turbid, water-like, aggressive and non aggressive liquids. -
Page 9: Specific Danger
If the product and supplied accessories are used for other purposes than the intended purpose, it is the responsibility of the user to check the suitability and admissibility. Product use not confirmed in writing by the manufacturer absolves the manufacturer of any liability. The manufacturer is not liable for consequences of incorrect treatment, use, maintenance, servicing and operation of the appliance, as well as normal wear and tear. -
Page 10: Identification
2.4 Identifi cation Fig. 1: Rating plate motor 1 Type 2 Serial number of the motor 3 Year of construction of the motor (last two digits of the serial number e.g. -18 for 2018) 4 CE-Identifi cation Fig. 2: Rating plate battery 1 Type 2 Electrical data 3 XXXX = month and year of construction; e.g. 0618 = June 2018 4 CE-Identifi cation... -
Page 11: Transport And Storage
3. Transport and storage 3.1 Transport Unpacking and checking condition of delivery ► Unpack the motor on receipt and check for transport damages. ► Report transport damages to the manufacturer immediately. ► Check that the consignment is complete as ordered. ►... -
Page 12: Starting Up
4. Starting up CAUTION When locking the quick fastener, the fingers can be squeezed! For locking, press on the slider with the flat hand. ► Open quick fastener before connecting the motor to the pump tube (→ Fig 3). Fig. 3: Unlock the quick fastener ► Mount the motor on the pump tube and lock it with quick fastener (→ Fig 4). Fig. - Page 13 ► Insert the battery into the motor B1 Battery (→ Fig. 5, item 1). ► When removing the battery, first release the lock by pressing it (→ Fig. 5, item 2). Then pull out the battery (→ Fig 5, item 3). Fig. 5: Motor B1 Battery - installation/removal of the battery ► Insert the battery into the motor B2 Battery, please note marking (→ Fig. 6, item 1).
- Page 14 ► Do not immerse the pump tube in the liquid deeper than the outrun piece. ► Fasten motor and pump tube in a way that the container cannot fall over. ► To start the motor, press the on/off switch (→ Fig. 7). After a long break, press the On/Off switch twice to exit sleep mode. During failure-free operation, the on/off switch lights up continuously. ► The flow rate can be increased (clockwise) or decreased (counterclockwise) by turning the speed con- troller (→ Fig. 7). Speed controller On/off switch Fig. 7: On/off switch and speed controller WARNING Danger of injury on the fingers due to free running drive shaft! • Never operate the motor without pump tube. Before opening the quick fastener, switch off the motor...
-
Page 15: Operation
5. Operation 3 For safe operation of the pump, sufficient space and a safe stand must be available. NOTICE Do not force the speed controller, otherwise it may be damaged. Then the motor will no longer work properly. WARNING Danger of injury on the fingers due to free running drive shaft! Before disconnecting or connecting the pump tube, necessarily switch off the motor and remove the battery. ► To start the motor, press the on/off switch (→ Fig. 7). After a long break, press the On/Off switch twice to exit sleep mode. During failure-free operation, the on/off switch lights up continuously. ► The flow rate can be increased (clockwise) or decreased (counterclockwise) by turning the speed con- troller (→ Fig. 7). -
Page 16: Cleaning
For safety reasons, damaged or defective batteries are considered to be lithium batteries that can not be diagnosed prior to transportation; those that have leaked or are deeply discharged or those that are defective / mechanically damaged. 8. Checking/Repair Repairs should only be made by the manufacturer or authorized Lutz dealers. Only use Lutz spare parts. ► For returns, use a designated (approved) packaging. The battery must be packed in such a way that a short circuit is prevented. 9. Waste disposal ►... -
Page 17: Annex
Annex Trouble shooting Fault Cause Remedy The motor does not start Motor is in sleep mode Press on/off switch twice when switched on. (downtime longer than 2 minutes). When switched on, the Battery voltage too low. Charge battery motor does not start and the on/off switch starts to flash. -
Page 19: Declaration Of Conformity
Translation of the original declaration of conformity We herewith declare under the sole responsibility that the following product complies with the EU Directives listed. Manufacturer: Lutz Pumpen GmbH Erlenstraße 5-7 D-97877 Wertheim Motor Product: Types: B1 Battery B2 Battery Relevant European Directives:... - Page 20 Lutz Pumpen GmbH Erlenstraße 5-7 D-97877 Wertheim Tel. (+49 93 42) 8 79-0 Fax (+49 93 42) 87 94 04 e-mail: info@lutz-pumpen.de http://www.lutz-pumpen.de Subject to technical changes. 01/20 Order No. 0698-301 Printed in Germany...
